Siemens EF3H150 Motor Circuit Protector
- 150A
- 3 Pole
- Bolt-On
Quantity
Siemens EF3H150 - 150A 3 Pole Motor Circuit Protector
Re-Certified
Quantity
Description
Built for heavy-duty motor control, the Siemens EF3H150 is a 150A, 3-pole magnetic-only circuit protector. It delivers instantaneous trip response to defend industrial motor branch circuits from damaging short circuits. The bolt-on E-frame unit installs into legacy Siemens and I-T-E panelboards. While it has been replaced by the FXD63A150, transitioning to the newer substitute requires specific panel modifications. Operating at up to 600VAC, this device includes a 14kAIC rating at 480V.Specifications
| Brand | Siemens |
|---|---|
| Part Number | EF3H150-R |
| Series | EF |
| Amperage | 150A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Amperage Range | Adjustable |
|---|
| Terminal Type | Lugs |
|---|---|
| For Use With | Motor Control Centers, Siemens / I-T-E Panelboards |
| Wire Gauge | 4-1/0 AWG (Cu), 2-1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Function Code | I |
| Trip Function | Instantaneous Only |
| Trip Adjustability | Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | UL 489, NEMA AB-1 |
| Approval | UL, CSA |
| Temp Rating | 40C |
| Construction Features | Motor Circuit Protector, Non-Interchangeable Trip |
