Eaton / Cutler-Hammer FDC2060L - 60A 2 Pole Molded Case Circuit Breaker

Brand Eaton / Cutler-Hammer
SKU FDC2060L
5.0
Rated 5.0 out of 5 stars
2 Reviews
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99

Eaton / Cutler-Hammer FDC2060L - 60A 2 Pole Molded Case Circuit Breaker

Brand Eaton / Cutler-Hammer
SKU FDC2060L
5.0
Rated 5.0 out of 5 stars
2 Reviews
Select Item Condition
Earn 0 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more

Eaton / Cutler-Hammer FDC2060L - 60A 2 Pole Molded Case Circuit Breaker

New

$0.01 No stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Engineered for heavy-duty power systems, the FDC2060L is a 2-pole, 60A molded case circuit breaker delivering exceptional fault-clearing performance. It features a thermal-magnetic trip unit for accurate long-time and instantaneous (LI) protection. This unit-mount breaker fits Eaton Series C panelboards. The "L" suffix indicates it includes line and load lugs. While the PDG22P0060TFFJ is the modern replacement, the FDC retains a superior 35kAIC rating at 600VAC. It is rated 100kAIC at 480V.

Specifications

Brand Eaton / Cutler-Hammer
Series FDC
Part Number FDC2060L
Amperage 60A
Voltage 600VAC, 250VDC
Poles 2
Phase 1
AIC Rating 200kA @ 240VAC, 100kA @ 480VAC, 35kA @ 600VAC, 22kA @ 250VDC
Mounting Style Unit Mount
Terminal Type Lugs
For Use With Eaton Series C Panelboards, Motor Control Centers, Switchboards
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed Thermal, Fixed Magnetic
Wire Gauge 14-1/0 AWG (Cu/Al)
Max Wire 1/0 AWG
Min Wire 14 AWG
Available Options Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Handle Mechanism
Accessories Line and Load Lugs
Standards CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489
Approval CE, CSA, HACR, UL
Temp Rating 40C
Construction Features Current Limiting, HACR Rated, Reverse Feed, Non-Interchangeable Trip
