Siemens QN2175RH - 175A 2 Pole Molded Case Circuit Breaker

Brand Siemens
SKU QN2175RH
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99

Siemens QN2175RH - 175A 2 Pole Molded Case Circuit Breaker

Brand Siemens
SKU QN2175RH
Select Item Condition
Earn 219 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more

Siemens QN2175RH - 175A 2 Pole Molded Case Circuit Breaker

New

$219.00 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
The QN2175RH is part of Siemens' Q Series, engineered for use as a main or branch breaker in compatible load centers and meter combinations. This 175-amp, 2-pole molded case circuit breaker utilizes a plug-on mounting style for straightforward installation. It serves as a direct replacement for the legacy MPD2175RH. Rated at 22 kAIC at 120/240VAC, this unit features a factory-installed reverse handle and common trip functionality to ensure comprehensive circuit protection.

Specifications

Brand Siemens
Series QNH
Part Number QN2175RH
Amperage 175A
Voltage 120/240VAC
Poles 2
Phase 1
AIC Rating 22kA @ 120/240VAC
Mounting Style Plug-On
Terminal Type Lugs
For Use With Siemens Load Centers, Meter Combinations
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed
Wire Gauge 4 AWG - 300 kcmil (Cu/Al)
Max Wire 300 kcmil
Min Wire 4 AWG
Available Options Padlock Attachment, Shunt Trip
Accessories Reverse Handle (Factory Installed)
Standards CSA C22.2 No. 5, UL 489
Approval CSA, UL
Temp Rating 40C
Construction Features High Interrupting Capacity, Reverse Handle, Common Trip, Requires 4 Panel Spaces
