Siemens / ITE FJ3S225 - 225A 3 Pole Molded Case Switch
Re-Certified
Quantity
Description
Part of the legacy F-frame family, the Siemens FJ3S225 is a 3-pole molded case switch designed for commercial circuit isolation. It functions solely as a disconnect, providing manual switching without automatic overcurrent protection. This bolt-on unit mounts into older Siemens and ITE F1, F2, and SB series panelboards. It serves as an exact drop-in replacement, avoiding the adapter kits required by the newer FXD63S250 substitute. Rated for 225A at 600VAC, it features high magnetic withstand.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | FJ3S225-R |
| Series | FJ |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 25kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FJ |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens / ITE F1, F2, SB1, SB2, SB3 Panelboards and Switchboards |
| Wire Gauge | 6 AWG - 350 kcmil (Cu/Al) |
| Max Wire | 350 kcmil |
| Min Wire | 6 AWG |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | NEMA AB-1, UL 1087, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Automatic (Disconnect) |
