ABB / General Electric SEHA24AT0030 Molded Case Circuit Breaker
- 30A
- 2 Pole
- Unit Mount
Quantity
ABB / General Electric SEHA24AT0030 - 30A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric SEHA24AT0030 - 30A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | SEHA24AT0030 |
| Series | SEHA |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 120VAC, 240VAC, 277VAC, 480Y/277VAC, 480VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 65kA @ 240VAC, 25kA @ 277VAC, 25kA @ 480Y/277VAC, 25kA @ 480VAC, 65kA @ 120/240VAC |
| Frame Type | E |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Spectra Series Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 12-3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 12 AWG |
| Trip Technology | Electronic Trip |
|---|---|
| Trip Function Code | LSI |
| Trip Function | Long-Time, Short-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Lug Kits |
|---|---|
| Accessories | Rating Plug (Included), Lugs Not Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, HACR, HID, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Current Limiting, True RMS Sensing, Interchangeable Rating Plugs, Reverse Feed |
Quantity
ABB / General Electric SEHA24AT0030 - 30A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | SEHA24AT0030 |
| Series | SEHA |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 120VAC, 240VAC, 277VAC, 480Y/277VAC, 480VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 65kA @ 240VAC, 25kA @ 277VAC, 25kA @ 480Y/277VAC, 25kA @ 480VAC, 65kA @ 120/240VAC |
| Frame Type | E |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Spectra Series Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 12-3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 12 AWG |
| Trip Technology | Electronic Trip |
|---|---|
| Trip Function Code | LSI |
| Trip Function | Long-Time, Short-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Lug Kits |
|---|---|
| Accessories | Rating Plug (Included), Lugs Not Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, HACR, HID, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Current Limiting, True RMS Sensing, Interchangeable Rating Plugs, Reverse Feed |
Description
The SEHA24AT0030 delivers reliable commercial circuit protection within the GE Spectra RMS line. This 30A, two-pole MCCB utilizes microprocessor-based sensing for accurate response to overcurrents. It mounts into GE Spectra Series panelboards and motor control centers. For modern upgrades, it is replaced by the XT1NU2030AFF000XXX using a retrofit kit. Rated 25kAIC at 480V, it features an interchangeable rating plug and configurable LSI trip settings for precise electrical coordination.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | SEHA24AT0030 |
| Series | SEHA |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 120VAC, 240VAC, 277VAC, 480Y/277VAC, 480VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 65kA @ 240VAC, 25kA @ 277VAC, 25kA @ 480Y/277VAC, 25kA @ 480VAC, 65kA @ 120/240VAC |
| Frame Type | E |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Spectra Series Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 12-3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 12 AWG |
| Trip Technology | Electronic Trip |
|---|---|
| Trip Function Code | LSI |
| Trip Function | Long-Time, Short-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Lug Kits |
|---|---|
| Accessories | Rating Plug (Included), Lugs Not Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, HACR, HID, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Current Limiting, True RMS Sensing, Interchangeable Rating Plugs, Reverse Feed |
Product FAQs
5 answersWhat equipment is the SEHA24AT0030 designed to fit?
This E-frame breaker is designed for use in GE Spectra Series panelboards, switchboards, and motor control centers. It features a bolt-on, unit mount configuration.
How does the LSI electronic trip unit function on this breaker?
The LSI designation indicates it has adjustable settings for Long-Time, Short-Time, and Instantaneous trip functions. This allows panel builders to precisely coordinate the breaker with other protective devices in the electrical system.
What wire sizes are accepted by the lugs on the SEHA24AT0030?
The factory lugs accept wire gauges from 12 AWG up to 3/0 AWG. They are rated for use with both aluminum and copper conductors.
Will this breaker arrive with GE or ABB branding?
ABB acquired GE Industrial Solutions, so this Spectra RMS breaker may feature either the GE or ABB logo. The physical dimensions, mounting, and electrical specifications remain identical regardless of the label.
What is the maximum interrupting capacity for this breaker at 240V versus 480V?
The breaker provides a 65kAIC rating at 120V and 240V. When applied to 480V or 277V systems, the interrupting capacity is 25kAIC.
