ABB XT5HU330ABFN000XXX Molded Case Circuit Breaker
- 300A
- 3 Pole
- Unit Mount
Quantity
ABB XT5HU330ABFN000XXX - 300A 3 Pole Molded Case Circuit Breaker
New
Quantity
Description
Designed for heavy-duty power distribution, the XT5HU330ABFN000XXX is a 3-pole, 300A molded case circuit breaker from the SACE Tmax XT5 series. It provides robust protection with fully adjustable thermal and magnetic trip units. This unit-mount breaker is designed for ABB ReliaGear neXT panelboards and switchboards. It serves as a replacement for discontinued T5H400BW breakers. Delivering 65kAIC at 480VAC, this HACR-rated breaker includes front terminals and supports reverse feeding.Specifications
| Brand | ABB |
|---|---|
| Series | XT5 |
| Amperage | 300A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 600VAC, 600VDC |
| Phase | 3 |
| AIC Rating | 150kA @ 240VAC, 65kA @ 480VAC, 35kA @ 600VAC, 70kA @ 250VDC, 50kA @ 500VDC, 35kA @ 600VDC |
| Amperage Range | 210-300A |
|---|
| Terminal Type | Lugs |
|---|---|
| For Use With | ReliaGear neXT Panelboards, Switchboards |
| Wire Gauge | 2x 2/0 AWG - 500 kcmil (Cu/Al) |
| Max Wire | 500 kcmil |
| Min Wire | 2/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Adjustable Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Motor Operator |
|---|---|
| Accessories | Lugs Not Included, Front Terminals Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CCC, CSA, cULus, HACR, IEC, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Current Limiting, Reverse Feed |
Product FAQs
6 answersCan the thermal and magnetic trip thresholds be adjusted on this XT5 breaker?
Yes. The thermal-magnetic trip unit features an adjustable long-time thermal overload setting and an adjustable instantaneous magnetic short-circuit setting for tailored protection.
What panels and switchboards are designed to accept this 300A breaker?
The XT5HU330ABFN000XXX is engineered for installation in ABB ReliaGear neXT panelboards and compatible switchboards designed to house Tmax XT5 frames.
What wire sizes and materials are permitted for the factory lugs on this breaker?
The pre-installed lugs are rated for both copper and aluminum conductors. Each phase accepts up to two wires ranging from 2/0 AWG to 500 kcmil.
Does this XT5 frame breaker include integral ground fault protection?
No. The standard LI trip unit provides long-time and instantaneous trip functions only. It does not provide built-in ground fault equipment protection.
Is this a plug-in style breaker or a unit mount breaker?
It is a unit mount breaker. It bolts directly to the mounting surface or busbars rather than plugging into a backplane.
Can this Tmax XT5 breaker replace obsolete GE Spectra G-frame breakers?
Yes. The Tmax XT5 series is the direct modern replacement for legacy GE Spectra SG breakers. Installing this unit into an older Spectra power panelboard requires a specific ABB retrofit kit.
