Allen-Bradley 509-BAD Starter
The Allen-Bradley 509-BAD is a starter with with a current rating of 27 Amps and a voltage rating of 600VAC. It has a coil volts of 115-120VAC at 60Hz. The 509-BAD has a surface mounting type.
Specifications
| Amperage | 27 A |
|---|---|
| Voltage | 600VAC |
| Phase | 3 |
| Poles | 3 |
| Coil Volts | 115-120VAC at 60Hz |
|---|
| Mounting Type | Surface |
|---|---|
| Terminal Connection | Saddle or Wire Clamps |
| Wire Gauge | AWG 14 to AWG 8 |
| NEMA Size | 1 |
| Action | Non-Reversing |
|---|
| Temperature Rating | -25 to 65 °C |
|---|
| Series | 509-B |
|---|---|
| Brand | Allen-Bradley |
| MPN | 509-BAD |
| UPC | 10781180160780 |
