Eaton / Moeller AZ-L10A Miniature Circuit Breaker
- 10A
- 1 Pole
- DIN Rail
Quantity
Eaton / Moeller AZ-L10A - 10A 1 Pole Miniature Circuit Breaker
New
Quantity
Description
Designed for commercial applications, the Eaton Moeller AZ-L10A miniature circuit breaker delivers reliable overcurrent protection. It is engineered for use within standard DIN rail enclosures and Moeller distribution boards. The single-pole breaker mounts onto DIN rails for quick integration. It replaces existing AZ frame setups and is superseded by the FAZ-B10/1. Rated 6kA at 230/400VAC, it features thermal-magnetic L-curve trip technology for line protection and finger-safe terminals.Specifications
| Brand | Eaton / Moeller |
|---|---|
| Part Number | AZ-L10A |
| Series | AZ |
| Amperage | 10A |
| Poles | 1 |
| Mounting Style | DIN Rail |
| Voltage | 220/380VAC |
| Phase | 1 |
| AIC Rating | 6kA @ 230/400VAC |
| Terminal Type | Box Lugs |
|---|---|
| For Use With | DIN Rail Enclosures, Moeller Distribution Boards |
| Wire Gauge | 18-4 AWG |
| Max Wire | 4 AWG |
| Min Wire | 18 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Curve | L |
| Trip Adjustability | Fixed |
| Available Options | Auxiliary Switch, Shunt Trip, Busbar System |
|---|---|
| Standards | IEC 60947-2, VDE 0641 |
| Approval | IEC, VDE |
| Temp Rating | -25C to 55C |
| Construction Features | Current Limiting, Trip-Free Mechanism, Reverse Feed |
Product FAQs
5 answersWhat is the modern Eaton replacement for the legacy Moeller AZ-L10A?
The AZ-L10A is a legacy AZ frame breaker that has been superseded by the Eaton FAZ series. The direct modern equivalent is the FAZ-B10/1, which provides the same 10A, single-pole protection for DIN rail mounting.
What application is the L trip curve on the AZ-L10A designed for?
The L trip curve is a legacy thermal-magnetic characteristic used primarily for general line protection. It is designed to protect resistive loads and circuits with low inrush currents, functioning similarly to modern B-curve miniature circuit breakers.
How is the AZ-L10A secured within a control panel?
This miniature circuit breaker snaps directly onto standard 35mm DIN rails. It is designed for quick integration into DIN rail enclosures and legacy Moeller distribution boards without requiring additional mounting hardware.
Are the terminals on the AZ-L10A suitable for large gauge control wiring?
Yes, the box lugs are oversized for a 10A breaker, accepting conductors as large as 4 AWG and as small as 18 AWG. This allows panel builders to upsize conductors to mitigate voltage drop over long wire runs.
Does the AZ-L10A provide finger-safe terminations?
Yes, the box lug terminals on this miniature circuit breaker are designed to be finger-safe, reducing the risk of accidental contact with live conductors during panel maintenance and troubleshooting.
