Eaton / Cutler-Hammer FDC3100 Molded Case Circuit Breaker
- 100A
- 3 Pole
- Unit Mount
Eaton / Cutler-Hammer
FDC3100
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
FDC3100
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer FDC3100 - 100A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
110A 3 Pole Molded Case Circuit Breaker
90A 3 Pole Molded Case Circuit Breaker
80A 3 Pole Molded Case Circuit Breaker
Description
Operating at up to 600VAC, the Eaton FDC3100 delivers dependable long-time and instantaneous (LI) protection for industrial networks. This 3-pole, 100A molded case circuit breaker is a core component of the Series C F-Frame family. The unit mount design allows integration into Eaton switchboards, panelboards, and F-Frame enclosures. Featuring load side lugs, it replaces older FD3100 units requiring higher interrupt capacity. It features a 100kAIC rating at 480V and reverse feed capability.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | FDC3100-R |
| Series | FDC |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 100kA @ 480VAC, 35kA @ 600VAC, 22kA @ 250VDC |
| Frame Type | FD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers, F-Frame Enclosures |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Current Limiting, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhat enclosures and panelboards are compatible with the FDC3100?
This breaker is designed for use in Eaton Series C panelboards, switchboards, motor control centers, and F-Frame enclosures.
What does the C in the FDC frame designation mean?
In Eaton Series C F-Frame nomenclature, the C indicates an extra-high interrupting capacity or current-limiting breaker. The FDC3100 provides up to 200kAIC at 240VAC and 100kAIC at 480VAC, which is significantly higher than standard FD or HFD models.
Can the FDC3100 be reverse fed?
Yes. Standard thermal-magnetic Series C F-Frame breakers like the FDC3100 do not have line and load markings and are suitable for reverse feed applications.
Can this breaker replace older Westinghouse FDC3100 models?
Yes. Eaton acquired the Westinghouse distribution equipment line. The modern Eaton or Cutler-Hammer FDC3100 is a direct replacement for older Westinghouse breakers with the exact same catalog number.
Is the FDC3100 suitable for DC applications?
Yes, it is rated for up to 250VDC with an interrupting capacity of 22kAIC. When used in DC systems, multiple poles may need to be wired in series depending on the specific voltage and grounding configuration.
Are the physical dimensions of the FDC3100 different from standard FD breakers?
No. All 3-pole Series C F-Frame breakers, including FD, HFD, and FDC models, share the exact same physical dimensions and mounting footprint.
