Eaton / Moeller FA2G40-3 - 40A 3 Pole Supplementary Protector
New
Quantity
Description
Built for industrial motor control, the Eaton FA2G40-3 delivers reliable supplementary protection for 40A circuits. This three-pole device safeguards control panels where branch protection is already provided. It mounts onto standard DIN rail and serves as a replacement for legacy Klockner Moeller units. It can be substituted with FAZ-K40/3 or FAZ-C40/3 models. Rated 10 kAIC at 480Y/277VAC, it features a G-curve trip optimized for inductive loads, finger-safe terminals, and a trip indicator.Specifications
| Brand | Eaton / Moeller |
|---|---|
| Part Number | FA2G40-3 |
| Series | FA |
| Amperage | 40A |
| Poles | 3 |
| Mounting Style | DIN Rail |
| Voltage | 240VAC, 480Y/277VAC, 400/415VAC, 60VDC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC, 10kA @ 480Y/277VAC, 10kA @ 400/415VAC, 10kA @ 60VDC |
| Terminal Type | Box Lugs |
|---|---|
| For Use With | DIN Rail Enclosures, Control Panels |
| Wire Gauge | 18-4 AWG |
| Max Wire | 4 AWG |
| Min Wire | 18 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Auxiliary Switch, Shunt Trip, Undervoltage Release |
|---|---|
| Standards | CSA C22.2 No. 235, IEC 60947-2, UL 1077 |
| Approval | CE, CSA, IEC, UR, VDE |
| Temp Rating | -25C to 75C |
| Construction Features | Current Limiting, Trip-Free Mechanism, Visual Trip Indicator |
