Eaton / Cutler-Hammer HFA3030 Molded Case Circuit Breaker
- 30A
- 3 Pole
- Bolt-On
Eaton / Cutler-Hammer
HFA3030
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
HFA3030
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer HFA3030 - 30A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
50A 3 Pole Molded Case Circuit Breaker
70A 3 Pole Molded Case Circuit Breaker
90A 3 Pole Molded Case Circuit Breaker
Description
Engineered for commercial power distribution, the Eaton HFA3030 is a 3-pole, 30A molded case circuit breaker. It delivers dependable thermal-magnetic protection to safeguard critical circuits. Designed for seamless integration, this unit mounts into Eaton Series C panelboards and switchboards. It is an excellent choice for maintaining existing systems, with the HFD3030 serving as its modern replacement.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | HFA3030-R |
| Series | HFA |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | HFA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Reverse Feed |
Product FAQs
6 answersWhat is the modern replacement for the legacy HFA3030 circuit breaker?
The HFA3030 is a legacy H-Frame component. For modern system upgrades, it is commonly replaced by the Eaton HFD3030, which provides equivalent 30A thermal magnetic protection for Series C panels.
Is the HFA3030 the same as the Cutler-Hammer or Westinghouse version?
Yes, the HFA3030 has been manufactured under the Westinghouse, Cutler-Hammer, and Eaton brands over its lifecycle. They share the same physical dimensions, mounting style, and electrical ratings.
Can I install the HFA3030 in a standard residential load center?
No, the HFA3030 is a commercial molded case circuit breaker designed specifically for Eaton Series C panelboards, switchboards, and motor control centers. It will not fit in standard residential load centers.
Can I adjust the trip curve on the HFA3030?
No, this breaker features a fixed thermal and fixed magnetic trip unit. It provides standard long-time and instantaneous (LI) protection, but the trip thresholds cannot be adjusted in the field.
Does the HFA3030 plug into the panelboard?
No, this is a bolt-on circuit breaker. It requires a bolted connection directly to the panelboard busbar, which provides a more secure mechanical and electrical connection than plug-on types.
Do I need to purchase lugs separately for the HFA3030?
The breaker typically includes standard load-side lugs that accept wire gauges from 14 AWG up to 1/0 AWG. Always verify terminal torque specifications during installation.
