Eaton / Westinghouse EB3010 Molded Case Circuit Breaker
- 10A
- 3 Pole
- Bolt-On
Eaton / Westinghouse
EB3010
Molded Case Circuit Breaker
Brand
Eaton / Westinghouse
SKU
EB3010
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Westinghouse EB3010 - 10A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
20A 3 Pole Molded Case Circuit Breaker
25A 3 Pole Molded Case Circuit Breaker
35A 3 Pole Molded Case Circuit Breaker
Description
Maintaining older systems requires exact-fit components like the 10A Eaton EB3010. This three-pole MCCB provides essential long-time and instantaneous protection. Its bolt-on configuration mounts securely into legacy Westinghouse and Eaton Pow-R-Line C panelboards. The EHD3010 is the recommended modern cross-reference. Featuring a 10kA interrupting capacity at 240VAC, this HACR-rated E-frame model utilizes proven AB De-Ion arc extinction technology.Specifications
| Brand | Eaton / Westinghouse |
|---|---|
| Series | EB |
| Amperage | 10A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 125/250VDC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 125/250VDC |
| Frame Type | EB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Pow-R-Line C Panelboards, Westinghouse Panelboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated |
Product FAQs
7 answersWhat panelboards are compatible with the EB3010 circuit breaker?
The EB3010 is a bolt-on molded case circuit breaker designed for use in Eaton Pow-R-Line C panelboards and legacy Westinghouse panelboards.
Can the EB3010 be used in 480V applications?
No, the EB3010 is strictly rated for a maximum of 240VAC. For 480V systems, an EHD or FDB frame breaker is typically required.
Is the EB3010 rated for direct current (DC) systems?
Yes, this breaker is rated for 125/250VDC applications with an interrupting capacity of 5kAIC.
Are the factory lugs on the EB3010 approved for aluminum wiring?
Yes, the standard lugs accept 14 to 1/0 AWG copper or aluminum (Cu/Al) conductors.
What is the difference between the EB3010 and the EHD3010?
Both are 10A, 3-pole E-frame breakers with identical physical dimensions and bolt-on mounting. However, the EB3010 is rated for a maximum of 240VAC, while the EHD3010 is rated for up to 480VAC.
Does the EB3010 mount to standard DIN rail?
No, this is a bolt-on molded case circuit breaker designed specifically to bolt directly to the busbars of compatible panelboard chassis. It is not designed for DIN rail mounting.
Can I adjust the trip curve on the EB3010 for specific loads?
No, the EB3010 features a fixed thermal and fixed magnetic trip unit. The long-time and instantaneous (LI) trip functions are factory set and cannot be adjusted in the field.
