ABB / Thomas & Betts LSB360600E Molded Case Circuit Breaker
- 600A
- 3 Pole
- Bolt-On
Quantity
ABB / Thomas & Betts LSB360600E - 600A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Built for demanding commercial and industrial applications, the ABB LSB360600E is a 600-amp, 3-pole molded case circuit breaker. It utilizes advanced microprocessor-based sensing to deliver accurate overcurrent protection. This electronic trip MCCB is engineered to bolt into legacy Westinghouse panelboards and switchboards. When upgrading facilities, the LD3600 serves as its modern replacement. The unit features a Seltronic trip system with adjustable long-time and instantaneous settings.Specifications
| Brand | ABB / Thomas & Betts |
|---|---|
| Series | LSB |
| Amperage | 600A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 22kA @ 250VDC |
| Frame Type | L |
|---|---|
| Terminal Type | Lugs |
| For Use With | Westinghouse Panelboards, Switchboards |
| Trip Technology | Electronic Trip |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Adjustable |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Lug Kits |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
Product FAQs
5 answersWhich panelboards accept the LSB360600E circuit breaker?
This L-frame breaker is engineered to bolt directly into legacy Westinghouse panelboards and switchboards.
What is a modern replacement for the legacy LSB360600E?
If you are upgrading your facility and need a modern equivalent, the Eaton LD3600 serves as a direct L-frame replacement for this legacy Thomas & Betts breaker.
How do you configure the trip curve on the LSB360600E?
This breaker features a Seltronic electronic trip unit with adjustable dials. You can manually set the long-time and instantaneous (LI) trip functions to match the specific overcurrent protection requirements of your load.
Is the LSB360600E suitable for DC power systems?
Yes. While primarily used in AC systems up to 600VAC, this breaker is also rated for DC applications up to 250VDC, providing a 22kA interrupting capacity for industrial DC circuits.
Can control accessories be added to the LSB360600E?
Yes, this breaker supports various internal accessories. Options such as shunt trips, auxiliary switches, and undervoltage releases can be integrated to meet specific control and signaling requirements.
