ABB / Thomas & Betts TBBJ3200 Molded Case Circuit Breaker
- 200A
- 3 Pole
- Plug-On
ABB / Thomas & Betts
TBBJ3200
Molded Case Circuit Breaker
Brand
ABB / Thomas & Betts
SKU
TBBJ3200
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / Thomas & Betts TBBJ3200 - 200A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
ABB / General ElectricTJK436200WL
200A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTJJ436200
200A 3 Pole Molded Case Circuit Breaker
200A 3 Pole Molded Case Circuit Breaker
Description
Part of the TBBJ series, this 200A, 3-pole molded case circuit breaker provides thermal-magnetic protection for commercial and industrial systems. It delivers reliable long-time and instantaneous trip functions to prevent overloads. Designed as a plug-on solution, the TBBJ3200 mounts into Thomas & Betts, Bryant, Westinghouse, and Eaton Type BR load centers. It serves as an exact replacement for older installations and crosses over to the BJ3200. Rated for 10kAIC at 240VAC with a common trip.Specifications
| Brand | ABB / Thomas & Betts |
|---|---|
| Part Number | TBBJ3200 |
| Series | TBBJ |
| Amperage | 200A |
| Poles | 3 |
| Mounting Style | Plug-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | TBBJ |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | Thomas & Betts Load Centers, Type BR Load Centers, Bryant Load Centers, Westinghouse Load Centers |
| Wire Gauge | 2 AWG - 300 kcmil (Al/Cu) |
| Max Wire | 300 kcmil |
| Min Wire | 2 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip, Main Breaker, Quick-Make/Quick-Break, Trip-Free Mechanism, Visual Trip Indicator |
Product FAQs
7 answersWhich load centers are compatible with the TBBJ3200?
This breaker is designed for use in Thomas & Betts, Type BR, Bryant, and Westinghouse load centers. Always verify panel labeling to ensure proper fit and UL compliance.
What wire sizes and materials are accepted by the TBBJ3200 lugs?
The box lugs accept 2 AWG to 300 kcmil wire. They are rated for both aluminum and copper conductors.
What type of trip unit does the TBBJ3200 feature?
It is equipped with a fixed thermal-magnetic trip unit. This provides long-time protection for overloads and instantaneous protection for short circuits.
Can the TBBJ3200 replace Eaton or Bryant BR breakers?
Yes, because it is compatible with Type BR load centers, it can serve as a replacement for 3-pole, 200A Eaton or Bryant BR breakers. Verify your panel allows for its use before installation.
How is the TBBJ3200 installed into the panel?
This breaker features a plug-on connection. It snaps directly onto the busbar of compatible load centers, eliminating the need for bolt-on hardware.
What is the interrupting capacity of the TBBJ3200?
This breaker has an interrupting rating of 10kA at 240VAC. Ensure the available fault current of your system does not exceed this rating to maintain safety and compliance.
Is the TBBJ3200 a current production breaker?
The TBBJ3200 is part of a legacy molded case circuit breaker family. It is typically sourced to service existing Thomas & Betts or compatible Type BR installations.
