ABB / General Electric THQDL21125 Molded Case Circuit Breaker
- 125A
- 2 Pole
- Plug-On
ABB / General Electric
THQDL21125
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
THQDL21125
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQDL21125 - 125A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric THQDL21125 - 125A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQDL21125 |
| Series | THQDL |
| Amperage | 125A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 120/240VAC |
| Frame Type | THQL |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE PowerMark Gold Load Centers, GE PowerMark Plus Load Centers |
| Wire Gauge | 1/0 AWG - 250 kcmil (Cu/Al) |
| Max Wire | 250 kcmil |
| Min Wire | 1/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Requires 4 Spaces, High Interrupting Capacity |
