ABB / General Electric TJK436Y600 Molded Case Switch
Quantity
Core Specs
See full specs
ABB / General Electric TJK436Y600 - 400A 3 Pole Molded Case Switch
Re-Certified
Quantity
Description
Part of the legacy J-Frame series, this molded case switch is engineered for commercial and industrial environments. It functions exclusively as a non-automatic disconnect, delivering safe and dependable manual circuit isolation. Designed for unit mounting, it fits perfectly into GE J600 panelboards, switchboards, and motor control centers. This model is an ideal substitute for the older TJJ436Y400. It features an interchangeable trip unit and supports reverse feed applications.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TJK436Y600-R |
| Series | TJK |
| Amperage | 400A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | UNVERIFIED |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE J600 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | (1) 6 AWG-600 kcmil (Cu/Al) or (2) 2/0 AWG-250 kcmil (Cu/Al) |
| Max Wire | 600 kcmil |
| Min Wire | 6 AWG |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included (TCAL43) |
| Standards | CSA C22.2 No. 5.1, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Automatic (Disconnect), Interchangeable Trip Unit |
