Square D HOM225GFI GFCI Miniature Circuit Breaker
- 25A
- 2 Pole
- Plug-On
Square D
HOM225GFI
GFCI Miniature Circuit Breaker
Brand
Square D
SKU
HOM225GFI
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D HOM225GFI - 25A GFCI Miniature Circuit Breaker
New
Quantity
Similar Items
20A GFCI Miniature Circuit Breaker
35A GFCI Miniature Circuit Breaker
15A GFCI Miniature Circuit Breaker
Description
Built for residential applications, the HOM225GFI delivers reliable 25A ground-fault protection for wet or damp locations. This 2-pole breaker is engineered specifically to mount into Square D Homeline load centers, providing a secure plug-on connection for fast installation. Rated at 10 kAIC at 120/240VAC, it features a pigtail neutral and Class A 6mA sensitivity to meet strict NEC safety requirements. The thermal-magnetic trip mechanism ensures consistent defense against overloads.Specifications
| Brand | Square D |
|---|---|
| Part Number | HOM225GFI |
| Series | HOM |
| Amperage | 25A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | HOM |
|---|---|
| Terminal Type | Screw/Clamp Terminal |
| For Use With | Square D Homeline Load Centers |
| Wire Gauge | 12-4 AWG (Al), 14-6 AWG (Cu) |
| Max Wire | 4 AWG (Al), 6 AWG (Cu) |
| Min Wire | 12 AWG (Al), 14 AWG (Cu) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Available Options | Padlock Attachment |
| Accessories | Pigtail Neutral |
| Standards | CSA C22.2 No. 5, UL 489, UL 943 |
| Approval | CSA, HACR, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated |
Product FAQs
6 answersCan I install the HOM225GFI in a Square D QO load center?
No. Homeline (HOM) circuit breakers are exclusively designed for Square D Homeline load centers. They are not interchangeable with QO series panels.
Can this 2-pole GFCI breaker be used for a straight 240V load that does not have a neutral wire?
Yes. You can use the HOM225GFI for 240V loads that do not require a load neutral. Connect the two hot wires to the breaker and leave the load neutral lug empty. However, the breaker's white pigtail must still be connected to the panel's neutral bus bar to power the internal GFCI circuitry.
What level of ground fault protection does the HOM225GFI provide?
This breaker provides Class A ground fault protection. It is designed to trip when a ground fault current of 6 milliamperes (mA) or more is detected, providing personnel protection against electrical shock.
Does the pigtail neutral need to be connected if I am only protecting a 240V load?
Yes. The white pigtail neutral must always be connected to the neutral bus bar in the load center. Without this connection, the breaker's push-to-test button and ground fault monitoring electronics will not function.
What is the difference between HOM225GFI and HOM225GFIC?
Both catalog numbers represent the exact same 25A 2-pole GFCI circuit breaker. The C suffix simply indicates that the breaker is sold in retail clamshell packaging rather than standard bulk cardboard packaging.
Is the HOM225GFI HACR rated?
Yes, this breaker is HACR rated, meaning it is approved for use with heating, air conditioning, and refrigeration equipment that requires a 25A 2-pole GFCI breaker.
