Federal Pacific NE2300 Molded Case Circuit Breaker
- 30A
- 2 Pole
- Plug-On
Quantity
Federal Pacific NE2300 - 30A 2 Pole Molded Case Circuit Breaker
New
Quantity
Description
Designed to handle demanding industrial applications, the NE2300 is a 300A, 2-pole molded case circuit breaker. It provides essential long-time and instantaneous trip functions to protect high-amperage commercial circuits. Engineered for legacy compatibility, this plug-on breaker installs into Federal Pacific NE panelboards. It serves as a functional equivalent to the NM022300. With an 18kAIC interrupt capacity at 240VAC, the unit is HACR rated and features a non-interchangeable trip.Specifications
| Brand | Federal Pacific |
|---|---|
| Part Number | NE2300 |
| Series | NE |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 240VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 18kA @ 240VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Federal Pacific NE Panelboards |
| Wire Gauge | 14-2 AWG |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | NEMA AB-1, UL 489 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Non-Interchangeable Trip, Reverse Feed |
Product FAQs
6 answersWhat panelboards accept the Federal Pacific NE2300 breaker?
This plug-on breaker is specifically designed to fit legacy Federal Pacific NE panelboards. It is not interchangeable with standard residential load centers or other FPE frame types.
What are the wire size limits for the NE2300 terminals?
The load side lugs accept wire gauges from 14 AWG up to 2 AWG. Ensure conductors are properly sized for the circuit amperage and torqued to manufacturer specifications.
Can the NE2300 be used in direct current applications?
Yes, this breaker is rated for 250V DC systems with a 10kA interrupting capacity, making it suitable for specific industrial DC control circuits as well as standard AC loads.
How does the trip unit function on the NE2300?
It features a fixed thermal-magnetic trip mechanism. The thermal element provides long-time delay for overloads, while the magnetic element offers instantaneous tripping during short-circuit events.
Is the NE2300 a suitable replacement for older FPE NE frame breakers?
Yes, it serves as a direct replacement for legacy 2-pole NE frame breakers in existing Federal Pacific enclosures, maintaining the original N Frame footprint and plug-in mounting style.
Can I adjust the trip settings on the NE2300?
No, this breaker features a fixed thermal-magnetic trip unit. The long-time and instantaneous trip functions are factory set and cannot be modified in the field.
