Siemens MPD2175 Molded Case Circuit Breaker
- 175A
- 2 Pole
- Plug-On
Quantity
Siemens MPD2175 - 175A 2 Pole Molded Case Circuit Breaker
New
Quantity
Description
Built for residential and commercial applications, the Siemens MPD2175 provides reliable main service protection. This 175A, two-pole breaker serves as the primary disconnect for your electrical system. It mounts into compatible Siemens and legacy Murray load centers using a plug-on connection. For panel upgrades, this unit is replaced by the newer QN2175 model. Rated at 10 kAIC at 120/240VAC, it features fixed thermal-magnetic trip technology and a common trip mechanism.Specifications
| Brand | Siemens |
|---|---|
| Series | MPD |
| Amperage | 175A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | MP |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Load Centers, Murray Load Centers |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Padlock Attachment |
|---|---|
| Accessories | Lugs Included |
| Standards | UL 489 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Main Breaker |
Product FAQs
6 answersWhat is the modern replacement for the legacy MPD2175?
The Siemens QN2175 is the direct drop-in replacement for the legacy MPD2175. Both breakers share the same physical footprint, making the QN2175 a standard substitute for panel upgrades.
How many panel spaces are required to install this main breaker?
The MPD2175 requires four full panel spaces for proper mounting in a compatible load center or meter combination.
Can I install this breaker in an older Murray panel?
Yes. Siemens acquired Murray, and this breaker is fully compatible with legacy Murray load centers that are designed to accept MPD frame main breakers.
Is the MPD2175 HACR rated?
Yes, this breaker is HACR rated, making it suitable for use with heating, air conditioning, and refrigeration equipment circuits.
Does this 2-pole breaker feature a common trip mechanism?
Yes, it features an internal common trip mechanism. An overload or short circuit on one pole will simultaneously trip both poles to safely disconnect power.
What is the ambient operating temperature rating for this breaker?
The MPD2175 is calibrated for a standard ambient operating temperature of 40 degrees Celsius (104 degrees Fahrenheit).
