Square D QE270VH Molded Case Circuit Breaker
- 70A
- 2 Pole
- Plug-On
Quantity
Square D QE270VH - 70A 2 Pole Molded Case Circuit Breaker
New
Quantity
Description
Part of the QE series line, this 70A breaker provides essential long-time and instantaneous trip functions. It is engineered to handle branch circuit protection across commercial environments. Designed specifically for Square D EZ Meter-Pak meter centers, the plug-on configuration ensures a precise fit. The included box lugs accommodate 8 AWG to 2 AWG wire sizes. With a solid 22kAIC rating at 240VAC, this HACR-rated unit offers high interrupting capacity for enhanced electrical safety.Specifications
| Brand | Square D |
|---|---|
| Part Number | QE270VH |
| Series | QE |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 240VAC |
| Frame Type | QE |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | Square D EZ Meter-Pak Meter Centers |
| Wire Gauge | 8 AWG - 2 AWG (Al/Cu) |
| Max Wire | 2 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | UL 489, CSA C22.2 No. 5 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity |
Product FAQs
7 answersWhat equipment is the QE270VH designed to fit?
This breaker is specifically designed for use as a tenant main breaker in Square D EZ Meter-Pak meter centers.
Can the QE270VH be installed in standard QO load centers?
No. While it is part of the QO family, the QE frame is specifically engineered for EZ Meter-Pak meter centers and is not compatible with standard QO residential load centers.
What wire sizes are accepted by the terminals on the QE270VH?
The included box lugs accommodate 8 AWG to 2 AWG aluminum or copper conductors.
How is the QE270VH installed in the meter center?
It features a plug-on connection for fast, secure installation directly into the bus of compatible EZ Meter-Pak meter centers.
What type of protection does the QE270VH provide?
It features a thermal-magnetic trip unit with fixed long-time and instantaneous functions, protecting downstream branch circuits from overloads and short circuits.
Is the QE270VH a direct replacement for older QE tenant breakers?
Yes, it directly replaces older 70A, 2-pole QE frame breakers used in Square D EZ Meter-Pak meter centers.
Is the QE270VH HACR rated?
Yes, this breaker is HACR rated, making it suitable for use with heating, air conditioning, and refrigeration equipment.
