Schneider Electric XB5AW34G5 Push Button
The Schneider Electric XB5AW34G5 is a push button with a current rating of 10 Amps and a voltage rating of 600VAC. It has a contact configuration of 1NO, 1NC. The XB5AW34G5 has a spring return actuator type.
Specifications
| Amperage | 10 A |
|---|---|
| Voltage | 600VAC |
| Series | XB5 |
| Poles | 1 |
| Mounting Type | Panel |
|---|---|
| Terminal Connection | Screw Clamp |
| Length (in) | 2.24 |
| Width (in) | 1.18 |
| Height (in) | 1.65 |
| Actuator Type | Spring Return |
|---|---|
| Action | Momentary |
| Contact Configuration | 1NO, 1NC |
| Approval | UL, CSA, EN, IEC, JIS, LROS, BV, DNV, GL, CCC, EAC, CE |
|---|---|
| NEMA Rating | 1, 2, 3, 3R, 4, 4X, 12, 13 |
| Standards | RoHS, REACh |
| Temperature Rating | -40 to 158 °F |
| Brand | Schneider Electric |
|---|---|
| Color | Red |
| MPN | XB5AW34G5 |
| UPC | 785901384571 |
