Siemens / ITE ETS4040 - 400A 3 Pole Molded Case Switch
Re-Certified
Quantity
Description
Built for commercial isolation, the Siemens ETS4040 is a 400A, 3-pole molded case switch. It delivers reliable non-automatic disconnect functionality for systems up to 600VAC. This unit mount switch fits into Siemens P4 and P5 panelboards. As a legacy component, it provides an exact replacement fit. For modern upgrades, it is replaced by the JXD63S400. Featuring a magnetic-only mechanism, this E-Frame device is designed strictly for switching rather than overcurrent protection.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | ETS4040-R |
| Series | ETS |
| Amperage | 400A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens P4, P5 Panelboards, Switchboards |
| Wire Gauge | (1) 1/0 AWG-500 kcmil or (2) 1/0 AWG-250 kcmil (Cu/Al) |
| Max Wire | 500 kcmil |
| Min Wire | 1/0 AWG |
| Trip Technology | Magnetic Only |
|---|
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Lugs Not Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Molded Case Switch, Non-Automatic |
