Siemens / ITE EF2B025 Molded Case Circuit Breaker
- 25A
- 2 Pole
- Unit Mount
Siemens / ITE
EF2B025
Molded Case Circuit Breaker
Brand
Siemens / ITE
SKU
EF2B025
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens / ITE EF2B025 - 25A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
40A 2 Pole Molded Case Circuit Breaker
50A 2 Pole Molded Case Circuit Breaker
80A 2 Pole Molded Case Circuit Breaker
Description
Supplying 25 amps of thermal-magnetic protection, this legacy E-Frame component is essential for maintaining older commercial power systems. It operates safely across a wide voltage range, including 600VAC and 250VDC applications. Engineers utilize this exact-fit solution for aging ITE FC, FCI, and CDP panelboards. It eliminates the need for complex retrofits and serves as a substitute for the ED62B025. With an 18kAIC rating at 240V, it ensures dependable fault clearing for legacy switchgear.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | EF2B025-R |
| Series | EF |
| Amperage | 25A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | EF |
|---|---|
| Terminal Type | Screw/Clamp Terminal |
| For Use With | ITE / Siemens FC, FCI, CDP Panelboards |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load-side Wire Binding Screws |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Interchangeable Trip |
Product FAQs
6 answersWhich panelboards are compatible with the EF2B025 circuit breaker?
This E-frame breaker is designed as a direct fit for legacy ITE and Siemens FC, FCI, and CDP panelboards.
Can the EF2B025 be utilized in direct current systems?
Yes, it is rated for 250VDC applications with an interrupting capacity of 10kAIC, making it suitable for specific DC control and power circuits.
What is the accepted wire size range for the EF2B025 terminals?
The standard screw and clamp terminals are designed to accept 14 AWG to 10 AWG copper or aluminum conductors.
How is the EF2B025 installed into an electrical enclosure?
It utilizes a bolt-on connection for unit-mount installations, securing directly to the bus or mounting pan of compatible legacy panelboards.
What is the modern replacement for the legacy EF2B025 breaker?
The EF frame is a discontinued legacy product. The newer ED frame, specifically the ED62B025, serves as the modern cross-reference, though panelboard retrofitting may be necessary.
How does the thermal-magnetic trip unit operate on the EF2B025?
It features a fixed, non-interchangeable trip unit providing long-time protection for thermal overloads and instantaneous protection for short-circuit faults.
