Siemens / ITE CF3B100 Molded Case Circuit Breaker
- 100A
- 3 Pole
- Bolt-On
Siemens / ITE
CF3B100
Molded Case Circuit Breaker
Brand
Siemens / ITE
SKU
CF3B100
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens / ITE CF3B100 - 100A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
50A 3 Pole Molded Case Circuit Breaker
40A 3 Pole Molded Case Circuit Breaker
30A 3 Pole Molded Case Circuit Breaker
Description
Built for heavy-duty industrial environments, this 100A current-limiting MCCB safeguards critical electrical circuits against severe faults. The bolt-on configuration mounts into classic Siemens switchboards, providing a seamless match without requiring modern adapters. Now superseded by the CED63B100, this original CF-frame breaker achieves a massive 200kAIC interrupting capacity at 480V by utilizing integral Amp-Trap fuses to restrict let-through energy.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | CF3B100-R |
| Series | CF |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 200kA @ 480VAC, 100kA @ 600VAC, 100kA @ 250VDC |
| Frame Type | CF |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Switchboards, Motor Control Centers |
| Wire Gauge | 14-1/0 AWG (Cu), 12-1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release |
|---|---|
| Accessories | Amp-Trap Current Limiters, Line and Load Lugs Included |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, Integral Amp-Trap Fuses, High Interrupting Capacity |
| Special Features | Current Limiting (Integrally Fused) |
Product FAQs
6 answersWhat equipment is the Siemens CF3B100 designed to fit?
This bolt-on CF frame breaker is designed for legacy Siemens and ITE switchboards and motor control centers. Because of its specific C-frame footprint and bolt-on connection, it cannot be installed in standard plug-on load centers.
How does the current-limiting feature of the CF3B100 work?
As a current-limiting molded case circuit breaker, it restricts the let-through energy during a severe electrical fault. This allows it to safely interrupt massive fault currents, achieving a 200kAIC rating at 240VAC and 480VAC, which protects downstream equipment from extreme thermal and magnetic stress.
What is the modern replacement for the legacy CF3B100 breaker?
The CF3B100 is a legacy Cordon-style breaker. If you are upgrading your panel, the modern Siemens equivalent with similar current-limiting capabilities is the CED63B100 (ED frame). However, upgrading to an ED frame may require different mounting straps or panel hardware compared to the original CF frame.
Is the CF3B100 rated for direct current (DC) systems?
Yes, in addition to its 600VAC rating, this breaker is rated for 250VDC applications. It provides a high interrupting capacity of 100kA at 250VDC, making it suitable for heavy-duty industrial DC circuits.
Can I adjust the trip settings on the CF3B100?
No, this breaker is equipped with a fixed thermal-magnetic trip unit. Both the long-time (overload) and instantaneous (short-circuit) trip functions are factory-set and cannot be adjusted in the field.
Are ITE and Siemens CF3B100 breakers the same?
Yes. Siemens acquired ITE, and many legacy breakers like the CF3B100 were manufactured under both brand names. An ITE CF3B100 and a Siemens CF3B100 share the exact same physical footprint, CF frame type, and electrical ratings.
