Siemens ED23S100A Molded Case Switch
Siemens
ED23S100A
Molded Case Switch
Brand
Siemens
SKU
ED23S100A
Quantity
Core Specs
See full specsShop with Confidence
Add an extra year of protection in your cart.
Siemens ED23S100A - 100A 3 Pole Molded Case Switch
New
Quantity
Similar Items
Description
Engineered for reliable power isolation, this 100A non-automatic molded case switch is part of the Sentron ED frame series. It mounts into Siemens P1, P2, and P3 panelboards, as well as standard switchboards. The 3-pole bolt-on unit features a self-protective instantaneous override set at 1000A and includes load side lugs. Designed to replace legacy models, it serves as a direct predecessor to the 3VA5110-1BB31-0AA0, ensuring seamless integration in commercial and industrial environments.Specifications
| Brand | Siemens |
|---|---|
| Part Number | ED23S100A |
| Series | ED2 |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Sentron Panelboards (P1, P2, P3), Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Automatic, Self-Protective Instantaneous Override (1000A), Reverse Feed, Non-Interchangeable Trip |
