Siemens Q2200BH Miniature Circuit Breaker
- 200A
- 2 Pole
- Plug-On
Quantity
Siemens Q2200BH - 200A 2 Pole Miniature Circuit Breaker
New
Quantity
Description
Engineered for heavy-duty applications, the Siemens Q2200BH is a 2-pole, 200A main circuit breaker. As part of the QPPH series, it provides reliable thermal-magnetic protection for residential and commercial systems. This plug-on unit installs into compatible Siemens load centers and multi-family metering products, requiring four full panel spaces. Rated at 22kAIC, it safely handles high fault currents and features a side-wired design to eliminate difficult S-bends during installation.Specifications
| Brand | Siemens |
|---|---|
| Part Number | Q2200BH |
| Series | Q |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 120/240VAC |
| Frame Type | Q |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Load Centers (Requires 4 Spaces) |
| Wire Gauge | #4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | #4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Shunt Trip |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip, HACR Rated, Main Breaker |
Product FAQs
5 answersWhat type of panels accept the Siemens Q2200BH?
This plug-on main breaker is designed for compatible Siemens load centers and multi-family metering products. Due to its physical size and 200A rating, it requires four full panel spaces for installation.
Does the Q2200BH use a plug-on or bolt-on connection?
The Q2200BH features a plug-on connection. It mounts directly into the busbar of compatible Siemens load centers. Bolt-on equivalents for Siemens panels typically use a different frame designation, such as the BQ series.
What is the difference between the Siemens Q2200B and the Q2200BH?
The Q2200B is a standard main breaker with a 10kAIC rating, while the Q2200BH is the high-interrupting version rated at 22kAIC. Both are 200A, 2-pole plug-on breakers that require four panel spaces.
Is there a 65kAIC version of this breaker available?
Yes. If your application requires a higher interrupting capacity, the Siemens Q2200BHH is the 65kAIC equivalent in the same QPPH form factor.
Can the Q2200BH be used in systems with high available fault currents?
Yes. The Q2200BH has an interrupting capacity of 22kAIC at 120/240VAC, making it suitable for residential and commercial applications where the available fault current exceeds the standard 10kAIC limit.
