Siemens HF3B090 Molded Case Circuit Breaker
- 90A
- 3 Pole
- Bolt-On
Siemens
HF3B090
Molded Case Circuit Breaker
Brand
Siemens
SKU
HF3B090
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens HF3B090 - 90A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
50A 3 Pole Molded Case Circuit Breaker
150A 3 Pole Molded Case Circuit Breaker
Description
Rated 65 kAIC at 480VAC, the Siemens HF3B090 3-pole, 90A molded case circuit breaker delivers reliable commercial power distribution. This F-frame device utilizes thermal-magnetic trip technology with adjustable magnetic settings. The bolt-on unit installs into Siemens Sentron, P1, P2, and P3 panelboards, switchboards, and motor control centers. For upgrades, this model is replaced by the HHED63B090. Engineered for high interrupting capacity, it supports 600VAC systems.Specifications
| Brand | Siemens |
|---|---|
| Part Number | HF3B090-R |
| Series | HF |
| Amperage | 90A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens Sentron Panelboards, P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Interchangeable Trip Unit |
Product FAQs
6 answersWhat panelboards are compatible with the HF3B090 circuit breaker?
This bolt-on breaker is designed for use in Siemens Sentron panelboards, as well as P1, P2, and P3 panelboards, switchboards, and motor control centers.
What does the H in the HF3B090 catalog number signify?
The H indicates a high interrupting capacity rating. This F-frame model provides up to 65kA interrupting capacity at 480VAC and 240VAC, which is higher than standard-rated versions.
Can the Siemens HF3B090 replace older ITE circuit breakers?
Yes, Siemens acquired ITE, and the HF3B090 is a direct replacement for legacy ITE Sentron F-frame breakers with the exact same catalog number.
Does the HF3B090 include line and load side lugs?
Because it is a bolt-on breaker, the line side mounts directly to the panel bus without lugs. It comes complete with load side lug terminals that accept 10 to 1/0 AWG copper or aluminum wire.
How does the trip unit on the HF3B090 operate?
It uses a thermal magnetic trip unit with a fixed thermal element for long-time overload protection and an adjustable magnetic element for instantaneous short-circuit protection.
Can this breaker be used in DC applications?
Yes, the HF3B090 is rated for up to 250VDC with a 10kA interrupting capacity, making it suitable for specific direct current systems.
