Square D KAL26200WB Molded Case Circuit Breaker
- 200A
- 2 Pole
- Unit Mount
Square D
KAL26200WB
Molded Case Circuit Breaker
Brand
Square D
SKU
KAL26200WB
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D KAL26200WB - 200A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
90A 2 Pole Molded Case Circuit Breaker
KAL362001021 3 Pole Circuit Breaker
200A 2 Pole Molded Case Circuit Breaker
Description
Built for heavy-duty industrial applications, the Square D KAL26200WB is a 2-pole, 200A molded case circuit breaker from the legacy K-Frame series. It delivers reliable thermal-magnetic protection for commercial facilities. This unit mount MCCB installs into Square D enclosures and switchboards. As a legacy component, it is officially replaced by the PowerPact J-Frame JDL26200. Rated 42kAIC at 240V, it features a factory-installed walking beam mechanical interlock to manage dual power sources.Specifications
| Brand | Square D |
|---|---|
| Part Number | KAL26200WB |
| Series | KAL |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | K |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Enclosures, Switchboards |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Walking Beam Mechanical Interlock (Factory Installed), Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated |
Product FAQs
6 answersIs the Square D KAL26200WB still in active production?
The KAL series is a legacy K-frame molded case circuit breaker. For new installations, Square D has transitioned to the PowerPact J-frame series. However, KAL breakers are still widely sourced as direct replacements for maintaining existing enclosures and switchboards.
What does the "WB" suffix indicate on the KAL26200WB?
The "WB" suffix designates that the breaker is factory-prepped for use with a walking beam mechanical interlock system. Implementing the interlock requires two breakers with the WB suffix, a walking beam assembly, and a compatible mounting pan.
Can I install the KAL26200WB on an I-Line panelboard bus?
No, this is a unit mount, feed-thru circuit breaker. It is designed to be hard-wired with lugs and mounted directly to the backpan in Square D enclosures or switchboards, rather than plugging into an I-Line distribution bus.
How does the adjustable magnetic trip function work on this K-frame breaker?
The thermal-magnetic trip unit features a fixed thermal element for long-time overload protection and an adjustable magnetic element. The adjustable magnetic dial allows electricians to set the instantaneous short-circuit trip threshold to coordinate with downstream devices or specific load inrush currents.
Is the KAL26200WB suitable for direct current (DC) systems?
Yes, in addition to its AC ratings, this breaker is rated for use in DC applications up to 250VDC, providing a 10kA interrupting capacity for DC circuits.
What are the lug wire size requirements for the KAL26200WB?
The standard feed-thru lugs on this breaker are designed to accept wire gauges ranging from 4 AWG up to 350 kcmil, and they are compatible with both aluminum and copper conductors.
