Square D FGA34030 Molded Case Circuit Breaker
- 30A
- 3 Pole
- I-Line
Square D
FGA34030
Molded Case Circuit Breaker
Brand
Square D
SKU
FGA34030
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D FGA34030 - 30A 3 Pole Molded Case Circuit Breaker
New
Quantity
Sold out
Quantity
Square D FGA34030 - 30A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Series | FGA |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480Y/277VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Square D I-Line Panelboards |
| Wire Gauge | 14-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, NOM, UL |
| Temp Rating | 40C |
Sold out
Quantity
Square D FGA34030 - 30A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Series | FGA |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480Y/277VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Square D I-Line Panelboards |
| Wire Gauge | 14-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, NOM, UL |
| Temp Rating | 40C |
Similar Items
30A 3 Pole Molded Case Circuit Breaker
30A 3 Pole Molded Case Circuit Breaker
30A 3 Pole Molded Case Circuit Breaker
Description
Engineered for robust industrial applications, the Square D FGA34030 is a 3-pole, 30A molded case circuit breaker. It utilizes a fixed thermal-magnetic trip unit to deliver dependable long-time and instantaneous (LI) circuit protection. This F-Frame unit mounts into Square D I-Line panelboards. As a legacy component, it requires only 3 inches of mounting space, making it ideal for replacing older units without upgrading to the wider 4.5-inch HGA36030 substitute. Rated 65kA at 240VAC.Specifications
| Brand | Square D |
|---|---|
| Series | FGA |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480Y/277VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Square D I-Line Panelboards |
| Wire Gauge | 14-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, NOM, UL |
| Temp Rating | 40C |
Product FAQs
6 answersWhat panelboards are compatible with the FGA34030?
This breaker is designed exclusively for use in Square D I-Line panelboards and switchboards. It features a plug-on phase connection on the line side and mechanical lugs on the load side.
Can I use a modern H-frame breaker to replace the legacy FGA34030?
While modern H-frame breakers (such as the HGA36030) serve as current-generation replacements, they require a 4.5-inch mounting space (1.5 inches per pole). The legacy FGA34030 uses a narrower 3-inch phase footprint (1 inch per pole). You must verify your I-Line panelboard has the physical space to accommodate the wider H-frame before upgrading.
How does the I-Line connection work on the FGA34030?
The I-Line design allows the breaker to plug directly into the panelboard bus assembly on the line side using spring-loaded jaws. This eliminates the need for line-side wiring and speeds up installation. The load side utilizes standard mechanical lugs for wire termination.
What type of trip unit is installed in the FGA34030?
This breaker features a fixed thermal-magnetic trip unit. It provides long-time (thermal) overload protection and instantaneous (magnetic) short-circuit protection. The trip settings are factory-fixed and cannot be adjusted in the field.
Does the interrupting capacity change depending on the system voltage?
Yes. The FGA34030 provides a 35kAIC interrupting rating on 480V and 277V AC systems. When installed in a 240V AC system, the interrupting capacity increases to 65kAIC.
What wire sizes are accepted by the load lugs on the FGA34030?
The factory-installed load lugs accept copper or aluminum conductors ranging from 14 AWG to 4 AWG. Ensure proper torque specifications are followed during installation as outlined on the breaker faceplate.
