Square D FI36030 Molded Case Circuit Breaker
- 30A
- 3 Pole
- I-Line
Square D
FI36030
Molded Case Circuit Breaker
Brand
Square D
SKU
FI36030
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D FI36030 - 30A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Quantity
Square D FI36030 - 30A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | FI36030 |
| Series | FI |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 200kA @ 480Y/277VAC, 200kA @ 480VAC, 100kA @ 600Y/347VAC, 100kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FI |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489, W-C-375B/GEN |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Common Trip, Trip-Free Mechanism |
| Special Features | Current Limiting |
Quantity
Square D FI36030 - 30A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | FI36030-R |
| Series | FI |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 200kA @ 480Y/277VAC, 200kA @ 480VAC, 100kA @ 600Y/347VAC, 100kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FI |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489, W-C-375B/GEN |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Common Trip, Trip-Free Mechanism |
| Special Features | Current Limiting |
Similar Items
20A 3 Pole Molded Case Circuit Breaker
60A 3 Pole Molded Case Circuit Breaker
90A 3 Pole Molded Case Circuit Breaker
Description
Delivering exceptional short-circuit protection, this 30-amp molded case circuit breaker is designed for commercial and industrial systems. The F-frame unit features thermal-magnetic trip technology with a 200kAIC rating at 480VAC. Installation is streamlined through its I-Line mounting style for Square D panelboards. For modern upgrades, this legacy component is replaced by the PowerPact HRA36030. Advanced current-limiting capabilities help minimize let-through energy during fault conditions.Specifications
| Brand | Square D |
|---|---|
| Part Number | FI36030-R |
| Series | FI |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 200kA @ 480Y/277VAC, 200kA @ 480VAC, 100kA @ 600Y/347VAC, 100kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FI |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489, W-C-375B/GEN |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Common Trip, Trip-Free Mechanism |
| Special Features | Current Limiting |
Product FAQs
7 answersWhat panelboards accept the FI36030 circuit breaker?
This I-Line style plug-in breaker is designed strictly for use in Square D I-Line panelboards and switchboards. It will not fit in standard QO, NQ, or NF series load centers.
What conductor sizes are supported by the FI36030 terminals?
The breaker comes equipped with factory-installed lugs that accept 14 AWG to 1/0 AWG wire. The terminals are rated for both copper and aluminum conductors.
Is the FI36030 suitable for direct current applications?
Yes, this thermal-magnetic breaker is rated for DC applications up to 250VDC, where it provides an interrupting capacity of 10kA.
Is the Square D FI36030 a current production model?
No, this unit is part of the legacy F-Frame series. Schneider Electric recommends modern PowerPact H-Frame I-Line circuit breakers as the active production replacement for older F-Frame units.
What makes the FI series different from standard FA or FH frames?
The FI frame is categorized as a current-limiting circuit breaker. It delivers a much higher interrupting capacity, up to 200kA at 480VAC and 100kA at 600VAC, to aggressively limit let-through current during severe short-circuit faults.
Are the thermal or magnetic trip settings adjustable on this breaker?
No. The FI36030 utilizes fixed long-time and instantaneous trip functions. You cannot adjust the thermal overload threshold or the magnetic short-circuit pickup in the field.
How does this breaker connect to the panelboard bus?
It utilizes an I-Line style plug-in connection. The breaker features integral jaw connectors that snap directly onto the busbars of an I-Line panelboard, completely eliminating the need for individual bolted bus connections.
