Schneider Electric EDB14060 Miniature Circuit Breaker
- 60A
- 1 Pole
- Bolt-On
Quantity
Schneider Electric EDB14060 - 60A 1 Pole Miniature Circuit Breaker
New
Quantity
Description
Engineered for demanding environments, this 60A single-pole breaker provides essential thermal-magnetic protection. It is part of the robust E-Frame family. The device mounts into Square D NF panelboards using a standard bolt-on configuration. It can substitute for EGB14060 or EJB14060 units. Delivering an 18 kAIC rating at 480Y/277V, it includes a Visi-Trip indicator to quickly identify tripped circuits. It is fully HACR rated.Specifications
| Brand | Schneider Electric |
|---|---|
| Part Number | EDB14060 |
| Series | EDB |
| Amperage | 60A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 480Y/277VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 25kA @ 120VAC, 25kA @ 240VAC, 18kA @ 480Y/277VAC, 25kA @ 120/240VAC |
| Frame Type | EDB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D NF Panelboards |
| Wire Gauge | 14 AWG - 2/0 AWG (Cu), 12 AWG - 2/0 AWG (Al) |
| Max Wire | 2/0 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Alarm Switch, Auxiliary Switch, Padlock Attachment, Shunt Trip |
| Standards | CSA C22.2 No. 5, HACR, NEMA AB 1, UL 489, IEC 60947-2 |
| Approval | CE, CSA, cULus, IEC, NOM, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator, Mercury Free, RoHS Compliant |
Product FAQs
6 answersWhat type of panelboard is the EDB14060 designed for?
This E-frame breaker is designed exclusively for use in Square D NF series panelboards. It features a bolt-on connection and cannot be installed in NQ panelboards or standard QO load centers.
Is there a higher interrupting rating equivalent for the EDB14060?
Yes. If your system requires a higher short-circuit current rating, you can use the EGB14060, which is rated 35kA at 277VAC, or the EJB14060, which is rated 65kA at 277VAC. Both share the same physical footprint and mount in NF panelboards.
Is the EDB14060 HACR rated?
Yes, this breaker is HACR rated. It is approved for use with heating, air conditioning, and refrigeration equipment that requires this specific protection standard.
What is the recommended lug torque for the EDB14060?
Always verify with the manufacturer label on the breaker, but the standard tightening torque for these lugs is typically 34.5 lb-in for 14 to 10 AWG wire, and 49.6 lb-in for 8 to 2/0 AWG wire.
Does this breaker feature a tripped circuit indicator?
Yes, it includes the Square D Visi-Trip indicator. When the breaker trips, the handle snaps to a midpoint position and a highly visible red indicator appears, making it easy to identify the tripped circuit in a crowded panel.
Can this 1-pole breaker be used on a 480Y/277V system?
Yes, the EDB14060 is rated for 277VAC, making it suitable for 277V single-phase branch circuits derived from a 480Y/277V three-phase system. It provides an 18kAIC interrupting rating at this voltage.
