Square D Q1L260 Molded Case Circuit Breaker
- 60A
- 2 Pole
- Unit Mount
Square D
Q1L260
Molded Case Circuit Breaker
Brand
Square D
SKU
Q1L260
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D Q1L260 - 60A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
ABB / General ElectricTEB122060WL
60A 2 Pole Molded Case Circuit Breaker
60A 2 Pole Molded Case Circuit Breaker
60A 2 Pole Molded Case Circuit Breaker
Description
Built for robust power distribution, this 60A Square D MCCB provides essential two-pole protection. The thermal-magnetic trip unit ensures accurate response to overloads. Featuring a feed-thru connection, it mounts into compatible Q1L series enclosures and OEM panelboards. It can be substituted with the QOU260 for modern panel upgrades. With a 10kAIC rating at 240VAC, the device includes a visible trip indicator to minimize downtime. It is HACR rated for HVAC applications.Specifications
| Brand | Square D |
|---|---|
| Part Number | Q1L260 |
| Series | Q1L |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | Q1L |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Q1L Enclosures, OEM Panels |
| Wire Gauge | 8-2 AWG (Al/Cu) |
| Max Wire | 2 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Padlock Attachment |
|---|---|
| Accessories | Lugs (Factory Installed) |
| Standards | UL 489, CSA C22.2 No. 5 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Visual Trip Indicator, HACR Rated, Common Trip |
Product FAQs
7 answersIs the Square D Q1L260 still manufactured, or is there a direct replacement?
The Q1L260 is a legacy circuit breaker. For modern panel upgrades or replacements, the Square D QOU260 is the official equivalent, offering the same 60A, 2-pole configuration and unit-mount design.
What types of panels and enclosures are compatible with the Q1L260?
This breaker is designed specifically for legacy Square D Q1L enclosures and various OEM panels that accept Q-Frame unit-mount breakers.
How is the Q1L260 circuit breaker mounted?
It features a unit-mount design with a feed-thru connection, meaning it is bolted or screwed directly to the panel chassis or enclosure rather than snapping onto a busbar.
Do I need special lugs for aluminum wire on the Q1L260?
No, the factory-installed lugs are rated for both aluminum and copper conductors, accepting wire sizes from 8 AWG to 2 AWG.
What does the LI trip function indicate on the Q1L260?
The LI designation means the thermal-magnetic trip unit provides Long-Time thermal protection against sustained overloads and Instantaneous magnetic protection against short circuits. Both settings are fixed.
Is the Q1L260 suitable for systems requiring a high interrupting rating?
No, this breaker has a standard interrupting rating of 10kAIC at 240VAC. It must only be installed in systems where the available fault current does not exceed 10,000 amps.
Does this breaker include a Visi-Trip indicator?
Yes, like many Square D Q-Frame breakers, it features a Visi-Trip visual indicator that makes it easy to identify a tripped breaker in a crowded panel.
