Square D A1B380 Molded Case Circuit Breaker
- 80A
- 3 Pole
- Bolt-On
Quantity
Square D A1B380 - 80A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Serving older commercial facilities, the Square D A1B380 is an 80A, 3-pole molded case circuit breaker. It provides fixed thermal-magnetic (LI) trip functions to protect 240VAC circuits. This long-body breaker installs into legacy Square D NA1B panelboards using a secure bolt-on style. It accepts 4-1/0 AWG wire. For modern upgrades, this unit is replaced by the QOB380 (requires a retrofit kit). Rated at 10kAIC, it includes a Visi-Trip indicator.Specifications
| Brand | Square D |
|---|---|
| Series | A1B |
| Amperage | 80A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | A1B |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D NA1B Panelboards |
| Wire Gauge | 4-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Visual Trip Indicator, Long Body |
Product FAQs
4 answersWhich panelboards are compatible with the A1B380 circuit breaker?
This breaker is specifically engineered for use in legacy Square D NA1B panelboards found in older commercial and industrial distribution systems.
What is the modern replacement for the obsolete A1B380?
Because the A1B series is discontinued, modern upgrades typically use a Square D QOB380 circuit breaker. Note that installing a QOB breaker into an NA1B panelboard requires a compatible retrofit kit.
How does the A1B380 indicate a tripped condition?
The breaker is equipped with a Visi-Trip indicator. When the breaker trips due to an overcurrent or short circuit, a highly visible red flag appears, allowing for quick fault recognition in the panelboard.
Can I adjust the trip settings on the A1B380?
No, this breaker features fixed thermal and fixed magnetic trip functions. The long-time and instantaneous trip settings are factory-set and cannot be adjusted in the field.
