Square D FHP36035 Molded Case Circuit Breaker
- 35A
- 3 Pole
- Bolt-On
Quantity
Square D FHP36035 - 35A 3 Pole Molded Case Circuit Breaker
New
Quantity
Description
Built for heavy-duty commercial applications, the Square D FHP36035 delivers dependable thermal-magnetic protection for 600VAC circuits. This 35-amp, three-pole breaker utilizes fixed long-time and instantaneous trip functions to prevent overloads and short circuits. The bolt-on design integrates seamlessly into Square D switchboards and panelboards. For facility upgrades, this legacy F-frame device is replaced by the PowerPact HGL36035. It features a 65kAIC rating at 240V.Specifications
| Brand | Square D |
|---|---|
| Part Number | FHP36035 |
| Series | FHP |
| Amperage | 35A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FHP |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Panelboards, Switchboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Shunt Trip, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, HACR Rated, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity |
Product FAQs
7 answersWhat type of panels accept the FHP36035 breaker?
This bolt-on circuit breaker is designed for installation in legacy Square D panelboards and switchboards configured for F-frame devices.
What is the modern replacement for the legacy FHP36035?
For facility upgrades, this legacy F-frame device is typically replaced by the PowerPact H-frame series, such as the HGL36035. Verify panel mounting requirements before upgrading.
Is the FHP36035 suitable for direct current applications?
Yes, this breaker is rated for DC systems up to 250VDC, where it provides an interrupting capacity of 10kA.
What wire materials and gauges are supported by the factory lugs?
The standard lugs on this breaker accept both copper and aluminum conductors ranging from 14 AWG to 1/0 AWG.
How does the thermal-magnetic trip unit operate on this model?
The fixed thermal-magnetic trip unit utilizes a bimetallic strip for long-time overload protection and an electromagnetic assembly for instantaneous short-circuit protection.
Can this breaker be mounted on a standard DIN rail?
No, this is a unit-mount, bolt-on breaker designed exclusively for bolted connections in Square D distribution equipment. It does not support DIN rail installation.
Can the trip settings on the FHP36035 be adjusted in the field?
No, this breaker features fixed thermal and fixed magnetic trip settings. It does not offer field-adjustable trip dials.
