Square D LA26400AC Molded Case Circuit Breaker
- 400A
- 2 Pole
- I-Line
Square D
LA26400AC
Molded Case Circuit Breaker
Brand
Square D
SKU
LA26400AC
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D LA26400AC - 400A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D LA26400AC - 400A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | LA26400AC |
| Series | LA |
| Amperage | 400A |
| Poles | 2 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 42kA @ 240VAC, 30kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | LA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards and Switchboards |
| Wire Gauge | (1) 1 AWG - 600 kcmil (Al/Cu) or (2) 1 AWG - 250 kcmil (Al/Cu) |
| Max Wire | 600 kcmil |
| Min Wire | 1 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Phase Connection AC (Factory Configured Jaw Arrangement) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator, Phase Connection AC |
Sold out
Quantity
Square D LA26400AC - 400A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Series | LA |
| Amperage | 400A |
| Poles | 2 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 42kA @ 240VAC, 30kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | LA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards and Switchboards |
| Wire Gauge | (1) 1 AWG - 600 kcmil (Al/Cu) or (2) 1 AWG - 250 kcmil (Al/Cu) |
| Max Wire | 600 kcmil |
| Min Wire | 1 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Phase Connection AC (Factory Configured Jaw Arrangement) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator, Phase Connection AC |
Similar Items
400A 2 Pole Molded Case Circuit Breaker
400A 2 Pole Molded Case Circuit Breaker
Description
Engineered for commercial power distribution, the Square D LA26400AC is a 2-pole, 400A molded case circuit breaker. It provides reliable thermal-magnetic protection with fixed thermal and adjustable magnetic trip settings. This unit installs into Square D I-Line panelboards and switchboards, utilizing a factory-configured AC phase jaw arrangement. For modern upgrades, this legacy LA frame is replaced by the PowerPacT LJA36400U31X. Rated for 42kAIC at 240VAC and 22kAIC at 600VAC.Specifications
| Brand | Square D |
|---|---|
| Part Number | LA26400AC |
| Series | LA |
| Amperage | 400A |
| Poles | 2 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 42kA @ 240VAC, 30kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | LA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards and Switchboards |
| Wire Gauge | (1) 1 AWG - 600 kcmil (Al/Cu) or (2) 1 AWG - 250 kcmil (Al/Cu) |
| Max Wire | 600 kcmil |
| Min Wire | 1 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Phase Connection AC (Factory Configured Jaw Arrangement) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator, Phase Connection AC |
Product FAQs
7 answersWhat does the "AC" suffix mean in the LA26400AC catalog number?
The "AC" suffix indicates that this 2-pole I-Line circuit breaker is factory-configured to connect to the A and C phases of the panelboard bus.
Which panelboards are compatible with the LA26400AC circuit breaker?
This breaker is designed exclusively for use in Square D I-Line panelboards and switchboards. It features an I-Line style plug-in connection and cannot be used in standard load centers or unit-mount applications.
What wire sizes are accepted by the lugs on the LA26400AC?
The standard lugs accept either one 1 AWG to 600 kcmil aluminum or copper wire, or two 1 AWG to 250 kcmil aluminum or copper wires per phase.
Is the trip unit on the LA26400AC adjustable?
Yes, it features a thermal-magnetic trip unit with a fixed thermal element for overload protection and an adjustable magnetic element for short-circuit protection.
Is the Square D LA frame still the current model for 400A I-Line breakers?
The LA series is a legacy frame. For modern upgrades or new installations, Schneider Electric has replaced the LA frame with the PowerPacT L-Frame series of molded case circuit breakers.
Can the LA26400AC be used in DC applications?
Yes, this breaker is rated for use in DC systems up to 250VDC, providing an interrupting capacity of 10kA at 250VDC.
Does the LA26400AC require a separate mounting bracket for installation?
No, it utilizes the Square D I-Line plug-on mounting system. The breaker jaws plug directly into the panelboard bus without the need for additional mounting brackets or hardware.
