Square D QOB220 Miniature Circuit Breaker
- 20A
- 2 Pole
- Bolt-On
Square D
QOB220
Miniature Circuit Breaker
Brand
Square D
SKU
QOB220
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QOB220 - 20A 2 Pole Miniature Circuit Breaker
New
Quantity
Quantity
Square D QOB220 - 20A 2 Pole Miniature Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | QOB220 |
| Series | QOB |
| Amperage | 20A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC, 48VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC, 5kA @ 48VDC |
| Frame Type | QOB |
|---|---|
| Terminal Type | Pressure Plate |
| For Use With | NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 14-8 AWG (Al/Cu) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489, HACR |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Quantity
Square D QOB220 - 20A 2 Pole Miniature Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | QOB220-R |
| Series | QOB |
| Amperage | 20A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC, 48VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC, 5kA @ 48VDC |
| Frame Type | QOB |
|---|---|
| Terminal Type | Pressure Plate |
| For Use With | NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 14-8 AWG (Al/Cu) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489, HACR |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Similar Items
QOB2201021 - 20A 2 Pole Miniature Circuit Breaker
QOB220VH1021 - 20A 2 Pole Miniature Circuit Breaker
25A 2 Pole Miniature Circuit Breaker
Description
Engineered for commercial environments, the QOB220 provides robust overcurrent protection. This two-pole miniature breaker operates at 120/240VAC with a standard 10kA interrupting rating. Designed for bolt-on installations, it fits into Square D NQ and legacy NQOD panelboards. The pressure plate terminals accept 14-8 AWG aluminum or copper wiring. A built-in Visi-Trip indicator allows personnel to quickly identify tripped circuits. It also carries an HACR rating for HVAC equipment.Specifications
| Brand | Square D |
|---|---|
| Part Number | QOB220 |
| Series | QOB |
| Amperage | 20A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC, 48VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC, 5kA @ 48VDC |
| Frame Type | QOB |
|---|---|
| Terminal Type | Pressure Plate |
| For Use With | NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 14-8 AWG (Al/Cu) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489, HACR |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Product FAQs
6 answersWhat panelboards accept the QOB220 circuit breaker?
This bolt-on circuit breaker is designed specifically for Square D NQ and NQOD commercial panelboards. It is not compatible with standard QO load centers, which require plug-on breakers.
Can I substitute a QO220 for the QOB220?
No. While they share the same internal thermal-magnetic trip mechanisms and 20-amp ratings, the QO220 is a plug-on breaker. The QOB220 requires a secure bolt-on connection to attach to the panelboard bus, meaning they cannot be used interchangeably.
Is the QOB220 HACR and SWD rated?
Yes, this 20-amp breaker is HACR rated for use with heating, air conditioning, and refrigeration equipment. It is also SWD (switching duty) rated, meaning it is certified for regularly switching 120V fluorescent lighting loads.
Are higher interrupting capacity versions of this breaker available?
Yes. If your electrical system requires a fault current rating above 10kAIC, the QOB220VH provides a 22kAIC rating at 120/240VAC. It shares the exact same physical footprint and bolt-on connection as the standard QOB220.
What type of wire is compatible with the QOB220 terminals?
The mechanical pressure plate terminals on this breaker are designed to accept copper or aluminum wiring ranging from 14 AWG to 8 AWG.
How does the Visi-Trip indicator work on this breaker?
When the breaker trips due to an overload or short circuit, the internal mechanism shifts and displays a bright red flag in the indicator window. This allows electricians or maintenance personnel to rapidly locate the faulted circuit within a crowded NQ or NQOD panelboard.
