Zinsco QCAL125 Molded Case Circuit Breaker
- 125A
- 2 Pole
- Plug-On
Zinsco
QCAL125
Molded Case Circuit Breaker
Brand
Zinsco
SKU
QCAL125
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Zinsco QCAL125 - 125A 2 Pole Molded Case Circuit Breaker
New
Quantity
Sold out
Quantity
Zinsco QCAL125 - 125A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Zinsco |
|---|---|
| Part Number | QCAL125 |
| Series | QC |
| Amperage | 125A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | QC |
|---|---|
| Terminal Type | Lugs |
| For Use With | Zinsco Load Centers |
| Wire Gauge | #4 AWG - 300 kcmil |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | UL 489 |
| Approval | UL |
| Temp Rating | 40°C |
| Construction Features | HACR Rated, Thick Series |
Sold out
Quantity
Zinsco QCAL125 - 125A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Zinsco |
|---|---|
| Part Number | QCAL125-R-R |
| Series | QC |
| Amperage | 125A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | QC |
|---|---|
| Terminal Type | Lugs |
| For Use With | Zinsco Load Centers |
| Wire Gauge | #4 AWG - 300 kcmil |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | UL 489 |
| Approval | UL |
| Temp Rating | 40°C |
| Construction Features | HACR Rated, Thick Series |
Similar Items
Description
Built for residential and commercial applications, this 125A Zinsco breaker delivers reliable thermal-magnetic protection. The two-pole unit features a 1.5-inch thick profile designed specifically for legacy Zinsco load centers. As an exact OEM-style fit, it requires no adapters for installation. Rated at 10 kAIC at 120/240VAC, the QCAL125 is HACR rated for HVAC equipment. For modern equivalents, this unit is replaced by the UBIZ2125.Specifications
| Brand | Zinsco |
|---|---|
| Part Number | QCAL125 |
| Series | QC |
| Amperage | 125A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | QC |
|---|---|
| Terminal Type | Lugs |
| For Use With | Zinsco Load Centers |
| Wire Gauge | #4 AWG - 300 kcmil |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | UL 489 |
| Approval | UL |
| Temp Rating | 40°C |
| Construction Features | HACR Rated, Thick Series |
Product FAQs
4 answersWhich load centers accept the Zinsco QCAL125 circuit breaker?
The QCAL125 is an exact OEM-style fit designed specifically for legacy Zinsco load centers that accept QC-type breakers. It features a 1.5-inch thick profile and installs directly onto the busbar without requiring any aftermarket adapters.
What is the modern aftermarket replacement for the QCAL125?
Because original Zinsco breakers are obsolete, Connecticut Electric manufactures a modern equivalent. The direct replacement catalog number is UBIZ2125 (or UBIZ2125-1), which is designed to fit the exact same legacy Zinsco panels.
Are there known safety issues with legacy Zinsco electrical panels?
Yes. Legacy Zinsco panels have well-documented reliability concerns, including breakers failing to trip during overcurrent events and arcing issues at the aluminum busbar connections. While replacement breakers can be used for temporary repairs or maintenance, most licensed electricians strongly recommend a complete panel upgrade when feasible.
Can the QCAL125 be used to supply power to HVAC equipment?
Yes. The QCAL125 is HACR rated, meaning it is certified for use with heating, ventilation, and air conditioning equipment that requires a breaker with this specific designation.
