ABB XT1HU3015AFD000XXX - 15A 3 Pole Molded Case Circuit Breaker

Brand ABB
SKU XT1HU3015AFD000XXX
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99

ABB XT1HU3015AFD000XXX - 15A 3 Pole Molded Case Circuit Breaker

Brand ABB
SKU XT1HU3015AFD000XXX
Select Item Condition
Earn 470 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more

ABB XT1HU3015AFD000XXX - 15A 3 Pole Molded Case Circuit Breaker

New

$470.40 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Serving as an upgrade to the legacy T1 series, the ABB XT1HU3015AFD000XXX brings advanced current limiting capabilities to modern distribution systems. This 15A, 3-pole molded case circuit breaker utilizes a fixed thermal magnetic trip within a compact XT1 frame. Engineered for unit mount installations, it fits seamlessly into ABB SACE Tmax XT panelboards and switchboards. Rated at 100kAIC at 240VAC, this HACR-rated breaker features double insulation and supports reverse feed applications.

Specifications

Brand ABB
Series XT1
Amperage 15A
Voltage 240VAC, 480VAC, 600Y/347VAC, 250VDC
Poles 3
Phase 3
AIC Rating 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600Y/347VAC, 50kA @ 250VDC
Mounting Style Unit Mount
Terminal Type Lugs
For Use With ABB SACE Tmax XT Panelboards, Switchboards
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed Thermal, Fixed Magnetic
Wire Gauge 10 AWG - 2/0 AWG (Cu/Al)
Max Wire 2/0 AWG
Min Wire 10 AWG
Available Options Shunt Trip, Auxiliary Switch, Undervoltage Release, Padlock Attachment, Motor Operator, Rotary Handle
Accessories Load Side Lugs
Standards CSA C22.2 No. 5, IEC 60947-2, UL 489
Approval CE, CSA, HACR, IEC, UL, cULus
Temp Rating -25C to 70C
Construction Features HACR Rated, Reverse Feed, Double Insulated
