Eaton / Cutler-Hammer LD3500 Molded Case Circuit Breaker
- 500A
- 3 Pole
- Unit Mount
Eaton / Cutler-Hammer
LD3500
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
LD3500
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer LD3500 - 500A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Eaton / Cutler-Hammer LD3500 - 500A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | LD3500 |
| Series | LD |
| Amperage | 500A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 22kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | (2) 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Interchangeable Trip Unit |
Quantity
Eaton / Cutler-Hammer LD3500 - 500A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | LD3500-R |
| Series | LD |
| Amperage | 500A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 22kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | (2) 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Interchangeable Trip Unit |
Similar Items
350A 3 Pole Molded Case Circuit Breaker
3 Pole Circuit Breaker
Description
Designed for high-amperage industrial environments, the Eaton LD3500 offers 500A of continuous power management. This Series C L-Frame molded case breaker delivers dependable protection for commercial facilities. It integrates into Eaton panelboards, switchboards, and motor control centers. The unit-mount configuration includes standard lugs designed for dual 3/0 AWG to 350 kcmil conductors. Featuring a 65 kAIC interrupt rating at 240V, this HACR-rated breaker utilizes fixed LI trip functions.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | LD3500 |
| Series | LD |
| Amperage | 500A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 22kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | (2) 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Interchangeable Trip Unit |
Product FAQs
6 answersDoes the LD3500 replace older Westinghouse L-frame breakers?
Yes. Eaton acquired the Westinghouse distribution equipment line, making this Series C breaker backwards compatible with many legacy Westinghouse and Cutler-Hammer L-frame panelboards and switchboards.
Which lug kit is supplied with this unit-mount breaker?
The LD3500 comes standard with the TA602LD lug kit installed on both the line and load sides. This kit is designed to accept dual conductors per phase.
Can the trip unit be upgraded if the circuit requirements change?
Yes. The LD3500 features an interchangeable frame design. It comes equipped with the LT3500T trip unit, but this block can be removed and swapped for a different Series C L-frame trip unit without replacing the entire breaker.
What higher-interrupting alternatives are available for the LD3500?
If your electrical system requires a short-circuit rating greater than 35kA at 480VAC, the HLD3500 provides 65kA at 480VAC, and the LDC3500 offers up to 100kA at 480VAC. Both share the same physical footprint.
Are field-installable internal accessories supported by this breaker?
Yes. The Series C L-frame supports a full range of internal accessories, including shunt trips, auxiliary switches, and undervoltage releases. These components drop directly into the designated cavities under the front cover.
What type of protection does the "LI" designation provide?
The LI trip unit delivers standard thermal-magnetic protection. The fixed thermal element (Long-Time) protects the circuit from sustained overloads, while the fixed magnetic element (Instantaneous) trips the breaker immediately during a short circuit.
