Eaton/Cutler-Hammer LFB3070R Circuit Breaker
Quantity
Core Specs
See full specs
Eaton/Cutler-Hammer LFB3070R 3 Pole Circuit Breaker
Re-Certified
Quantity
Description
Cutler-Hammer LFB3070R 3 pole Circuit Breakers 15-70A 600 VAC
Eaton / Cutler-Hammer 3 poles circuit breakers comes with the current rating of 15-70A and voltage rating of 600 VAC. It is complete with Thermal Magnetic protection.
Specifications
| Brand | Eaton/Cutler-Hammer |
|---|---|
| Part Number | LFB3070R |
| Series | LFB |
| Amperage | 70A |
| Poles | 3 |
| Voltage | 600V |
Product FAQs
5 answersWhat type of circuit breakers is the LFB3070R compatible with?
The LFB3070R is a current limiter module designed to mount to the load end of 3-pole F-Frame (FB) thermal-magnetic circuit breakers rated between 15A and 70A.
What is the interrupting capacity (AIC) provided by this current limiter?
When properly installed with a compatible FB circuit breaker, the LFB3070R provides an interrupting capacity of up to 200,000 AIC at 600 VAC.
How does the LFB3070R mount to the circuit breaker?
The current limiter bolts directly to the load end of the circuit breaker. It uses molded projections and grooves to ensure proper alignment and prevent installation on incompatible breaker frames.
Does the circuit breaker need to be removed from the panel to install this limiter?
Yes. The circuit breaker must be completely de-energized and removed from the electrical system before bolting on the current limiter module.
What is the alternate style number for the LFB3070R?
This current limiter is frequently identified by the Westinghouse or Cutler-Hammer style number 2607D44G03.
