Cutler-Hammer / Westinghouse LD3600F Circuit Breaker Frame Only
- 600A
- 3 Pole
- Bolt-On
Quantity
Cutler-Hammer / Westinghouse LD3600F 3 Pole Circuit Breaker Frame Only
New
Quantity
Quantity
Cutler-Hammer / Westinghouse LD3600F 3 Pole Circuit Breaker Frame Only
New
Quantity
| Brand | Cutler-Hammer / Westinghouse |
|---|---|
| Part Number | LD3600F |
| Series | LD |
| Amperage | 600A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600 V |
| Phase | 3 |
| Approval | UL 489 Listed and CSA Certified |
|---|
Quantity
Cutler-Hammer / Westinghouse LD3600F 3 Pole Circuit Breaker Frame Only
Re-Certified
Quantity
| Brand | Cutler-Hammer / Westinghouse |
|---|---|
| Part Number | LD3600F |
| Series | LD |
| Amperage | 600A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600 V |
| Phase | 3 |
| Approval | UL 489 Listed and CSA Certified |
|---|
Description
LD3600F - EATON Molded Case Circuit Breaker Frame
• Authentic Cutler-Hammer / Westinghouse Product
• Thermal Magnetic Ld Frame
• 600 Vac At 50/60 Hz
• 600 Ampere
• 3 Pole
• Interrupting Rating 65 Kiloampere At 240 Vac 35 Kiloampere At 480 Vac 25 Kiloampere At 600 Vac 22 Kiloampere At 250 Vdc (Ul)
• 85 Kiloampere At 240 Vac 45 Kiloampere At 415 Vac 20 Kiloampere At 690 Vac/250 Vdc (Iec)
• Terminal Lugs and Trip Unit Not Included
• Size 8.25 Inch W X 4.062 Inch D X 10.75 Inch H
• Ld Model
Specifications
| Brand | Cutler-Hammer / Westinghouse |
|---|---|
| Part Number | LD3600F |
| Series | LD |
| Amperage | 600A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600 V |
| Phase | 3 |
| Approval | UL 489 Listed and CSA Certified |
|---|
Product FAQs
5 answersDoes the LD3600F frame include a trip unit?
No. The LD3600F is a frame-only component. You must separately source and install a compatible Eaton Series C L-Frame trip unit before placing the breaker into service.
What lug kit is compatible with the LD3600F circuit breaker?
The standard 3-pole lug terminal kit for the LD3600F is catalog number 3TA603LDK. Because terminal lugs are not included with the frame, they must be purchased separately to match your specific conductor size and material requirements.
What types of equipment accept the LD3600F breaker frame?
This Eaton Series C L-Frame is designed for installation in commercial and industrial panelboards, switchboards, motor control centers, and standalone enclosures that accommodate 600-amp frames.
Are Cutler-Hammer, Westinghouse, and Eaton LD3600F frames identical?
Yes. Eaton acquired the Cutler-Hammer and Westinghouse circuit breaker lines. An LD3600F frame bearing any of these three brand names is functionally identical and fully interchangeable.
What internal accessories are compatible with this L-Frame breaker?
The LD3600F accepts standard Eaton Series C L-Frame internal accessories. This includes shunt trips, undervoltage releases, auxiliary switches, and bell alarms, which install directly into the designated accessory cavities of the frame.
