Eaton / Cutler-Hammer CSR2225N - 225A 2 Pole Main Breaker Kit
New
Quantity
Description
Manufactured by Eaton, the CSR2225N is a 2-pole, 225A main breaker kit. Built for residential and commercial applications, it delivers reliable long-time and instantaneous (LI) thermal-magnetic protection for main service entrances. This bolt-on unit is specifically designed to install into Eaton Type CH load centers, as well as Type ECC and ECB unit enclosures. It serves as a replacement for the legacy CSR2225. Rated for 120/240VAC systems, the breaker features a 25kAIC interrupt capacity.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | CSR |
| Amperage | 225A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 25kA @ 120/240VAC |
| Frame Type | CSR |
|---|---|
| Terminal Type | Lugs |
| For Use With | Type CH Load Centers, Type ECC Unit Enclosures, Type ECB Unit Enclosures |
| Wire Gauge | #2 AWG - 300 kcmil |
| Max Wire | 300 kcmil |
| Min Wire | 2 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch |
|---|---|
| Accessories | Lugs Included, Mounting Hardware |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Main Breaker, HACR Rated |
