Eaton / Cutler-Hammer EDB3225 Molded Case Circuit Breaker
- 225A
- 3 Pole
- Bolt-On
Eaton / Cutler-Hammer
EDB3225
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
EDB3225
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer EDB3225 - 225A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Eaton / Cutler-Hammer EDB3225 - 225A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EDB3225 |
| Series | EDB |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 125VDC |
| Phase | 3 |
| AIC Rating | 22kA @ 240VAC, 10kA @ 125VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line 1a, 2a, 3a Panelboards, Series C F-Frame Enclosures |
| Wire Gauge | 4 AWG - 4/0 AWG (Al/Cu) |
| Max Wire | 4/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Lugs (Included) |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Current Limiting, Non-Interchangeable Trip |
Quantity
Eaton / Cutler-Hammer EDB3225 - 225A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EDB3225 |
| Series | EDB |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 125VDC |
| Phase | 3 |
| AIC Rating | 22kA @ 240VAC, 10kA @ 125VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line 1a, 2a, 3a Panelboards, Series C F-Frame Enclosures |
| Wire Gauge | 4 AWG - 4/0 AWG (Al/Cu) |
| Max Wire | 4/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Lugs (Included) |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Current Limiting, Non-Interchangeable Trip |
Similar Items
100A 3 Pole Molded Case Circuit Breaker
225A 3 Pole Molded Case Circuit Breaker
225A 3 Pole Molded Case Circuit Breaker
Description
Engineered for commercial and industrial electrical systems, this 225A F-Frame breaker delivers robust thermal-magnetic trip functionality. It installs into Eaton Pow-R-Line 1a, 2a, and 3a panelboards as well as Series C enclosures. Featuring a 22kAIC rating at 240VAC, the unit includes reverse feed capability and HACR certification for heating and cooling applications.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EDB3225 |
| Series | EDB |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 125VDC |
| Phase | 3 |
| AIC Rating | 22kA @ 240VAC, 10kA @ 125VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line 1a, 2a, 3a Panelboards, Series C F-Frame Enclosures |
| Wire Gauge | 4 AWG - 4/0 AWG (Al/Cu) |
| Max Wire | 4/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Lugs (Included) |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Current Limiting, Non-Interchangeable Trip |
Product FAQs
6 answersWhich panelboards accept the EDB3225 circuit breaker?
The EDB3225 is a bolt-on breaker designed specifically for Eaton Pow-R-Line 1a, 2a, and 3a panelboards. It can also be installed in standalone Series C F-Frame enclosures.
Can the Eaton EDB3225 be used in direct current (DC) systems?
Yes, in addition to its 240VAC rating, this thermal-magnetic breaker is rated for DC applications up to 125VDC with an interrupting capacity of 10kA.
Is the EDB3225 suitable for reverse-feed applications?
Yes, Eaton Series C F-frame thermal-magnetic circuit breakers like the EDB3225 do not have line and load restrictions, making them fully suitable for reverse-feed installations.
Is there a difference between the Eaton EDB3225 and the Cutler-Hammer EDB3225?
No. Eaton acquired Cutler-Hammer, and the EDB3225 part number remains the exact same Series C F-frame breaker regardless of which brand name is printed on the label.
What are the direct replacements if my system requires a higher interrupting rating than 22kA?
The EDB3225 provides 22kA at 240VAC. If your fault current calculations require a higher rating in the exact same F-frame footprint, you can use the EDS3225 (42kA), ED3225 (65kA), or EDH3225 (100kA).
What does the LI trip function on the EDB3225 mean for protection?
The LI designation indicates a thermal-magnetic trip unit with Long-Time (L) protection for standard overloads and Instantaneous (I) protection for immediate short-circuit clearing. Both the thermal and magnetic trip points are fixed on this specific model.
