Eaton / Cutler-Hammer EGS1020FFB Molded Case Circuit Breaker
- 20A
- 1 Pole
- Bolt-On
Quantity
Eaton / Cutler-Hammer EGS1020FFB - 20A 1 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Part of the Series G family, the EGS1020FFB is a 1-pole, 20A molded case circuit breaker built for commercial and industrial applications. It provides reliable thermal-magnetic protection with an 85kAIC rating at 240V and 35kAIC at 277V. This EG-frame breaker mounts into Eaton Pow-R-Line panelboards using a secure bolt-on connection. As the Series G line is phasing out, this unit is slated to be replaced by the Power Defense PDG11M0020TFFB, making it ideal for maintaining existing systems.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | EGS |
| Amperage | 20A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 277VAC, 125VDC, 347VAC |
| Phase | 1 |
| AIC Rating | 85kA @ 240VAC, 35kA @ 277VAC, 35kA @ 125VDC, 22kA @ 347VAC |
| Frame Type | EG |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Pow-R-Line Panelboards |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Handle Mechanism |
|---|---|
| Accessories | Load Side Lugs Included, Mounting Hardware |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, KEMA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Current Limiting |
Product FAQs
6 answersWhich panelboards are compatible with the EGS1020FFB circuit breaker?
This breaker is designed for use in Eaton Pow-R-Line panelboards that accommodate Series G EG-frame bolt-on breakers.
What wire sizes are supported by the standard lugs on the EGS1020FFB?
The factory-installed lugs accept wire gauges from 14 AWG up to 1/0 AWG. Ensure you use properly rated copper or aluminum conductors as specified by local electrical codes.
Is the EGS1020FFB rated for direct current (DC) applications?
Yes, this breaker is rated for up to 125VDC with an interrupting capacity of 35kA, making it suitable for specific DC control circuits and battery systems.
How does the thermal-magnetic trip unit function on the EGS1020FFB?
It features a fixed thermal and fixed magnetic trip unit. The thermal element provides long-time delayed protection against overloads, while the magnetic element offers instantaneous protection against short circuits.
How does the EGS1020FFB connect to the panelboard bus?
This is a bolt-on breaker designed to bolt directly to the bus of compatible Eaton Pow-R-Line panelboards. Standard mounting hardware is required for a secure electrical connection.
What does the FFB suffix indicate in the EGS1020FFB catalog number?
In the Eaton Series G nomenclature, FF indicates a fixed thermal and fixed magnetic trip unit, and B signifies a bolt-on connection type.
