Eaton / Cutler-Hammer EHB3010 Molded Case Circuit Breaker
- 10A
- 3 Pole
- Bolt-On
Quantity
Eaton / Cutler-Hammer EHB3010 - 10A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Serving industrial three-phase applications, this 10-amp molded case circuit breaker provides essential thermal-magnetic protection for commercial facilities. This unit fastens securely into Eaton Pow-R-Line 4B and traditional Westinghouse panelboards. When maintaining older infrastructure, facility managers can also utilize the EHD3010 as an exact functional cross-reference. With a 14kAIC rating at 480Y/277V and a 10kAIC DC rating, it handles diverse electrical demands safely.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EHB3010 |
| Series | EHB |
| Amperage | 10A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480Y/277VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 14kA @ 480Y/277VAC, 10kA @ 250VDC |
| Frame Type | EHB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Pow-R-Line 4B Panelboards, Westinghouse Panelboards |
| Wire Gauge | 14-10 AWG |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lug Terminals |
| Standards | UL 489, CSA C22.2 No. 5.1, NEMA AB 1 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Non-Interchangeable Trip |
Product FAQs
6 answersWhich panelboards are compatible with the EHB3010 circuit breaker?
This breaker is designed for use in Eaton Pow-R-Line 4B panelboards and legacy Westinghouse panelboards. It provides a direct fit for these systems, eliminating the need for a complete panel upgrade.
What wire sizes do the lugs on the EHB3010 accept?
The included load-side lugs accept wire gauges from 14 AWG to 10 AWG. Ensure proper torque specifications are followed during installation.
Can the EHB3010 be used in DC voltage applications?
Yes, in addition to its AC ratings, this breaker is rated for up to 250VDC with an interrupting capacity of 10kAIC, making it suitable for specific direct current circuits.
How does the EHB3010 mount into the panelboard?
It features a bolt-on connection for secure mounting to the panelboard bus, which is standard for E-Frame breakers in commercial and industrial distribution panels.
Is the Eaton EHB3010 an obsolete breaker?
Yes, the EHB series is a legacy molded case circuit breaker originally manufactured by Cutler-Hammer and Westinghouse. Exact replacements are still sourced to maintain existing infrastructure without retrofitting.
What type of trip unit does the EHB3010 use?
It uses a thermal-magnetic trip unit with fixed long-time and instantaneous (LI) trip functions. Both the thermal and magnetic elements are fixed and cannot be adjusted in the field.
