Eaton / Cutler-Hammer HFD3035 - 35A 3 Pole Molded Case Circuit Breaker

Brand Eaton / Cutler-Hammer
SKU HFD3035
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99

Eaton / Cutler-Hammer HFD3035 - 35A 3 Pole Molded Case Circuit Breaker

Brand Eaton / Cutler-Hammer
SKU HFD3035
Select Item Condition
Earn 638 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more

Eaton / Cutler-Hammer HFD3035 - 35A 3 Pole Molded Case Circuit Breaker

Re-Certified

$638.00 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Belonging to the Series C family, the Eaton HFD3035 delivers 35A of industrial-grade MCCB performance. The 'H' prefix designates its high interrupting capacity for demanding environments. This F-frame device utilizes a panel mount configuration for Eaton panelboards and motor control centers. It is reverse feed capable and superseded by the PDG23M0035TFFJ. Rated 65kAIC at 480VAC, it features fixed thermal-magnetic trip technology for precise long-time and instantaneous (LI) protection.

Specifications

Brand Eaton / Cutler-Hammer
Series HFD
Part Number HFD3035
Amperage 35A
Voltage 240VAC, 480VAC, 600VAC, 250VDC
Poles 3
Phase 3
AIC Rating 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 22kA @ 250VDC
Mounting Style Panel Mount
Terminal Type Lugs
For Use With Eaton Series C Panelboards, Switchboards, Motor Control Centers
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed Thermal, Fixed Magnetic
Wire Gauge 14-1/0 AWG (Cu/Al)
Max Wire 1/0 AWG
Min Wire 14 AWG
Available Options Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Terminal Shields, Handle Tie
Accessories Load Side Lugs
Standards CSA C22.2 No. 5, HACR, NEMA AB-1, UL 489
Approval CSA, UL
Temp Rating 40C
Construction Features HACR Rated, High Interrupting Capacity, Reverse Feed, HID Rated
