Eaton / Cutler-Hammer LA3200 Molded Case Circuit Breaker
- 200A
- 3 Pole
- Bolt-On
Eaton / Cutler-Hammer
LA3200
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
LA3200
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer LA3200 - 200A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
250A 3 Pole Molded Case Circuit Breaker
250A 3 Pole Molded Case Circuit Breaker
300A 3 Pole Molded Case Circuit Breaker
Description
Engineered for industrial applications, the Eaton LA3200 provides reliable overcurrent protection for heavy-duty systems. This 200A, 3-pole device is part of the classic L-Frame family. It installs into vintage Westinghouse PRL4 panelboards, switchboards, and motor control centers. For modern upgrades, this unit is replaced by the Series C LD3200. Delivering a 30kAIC rating at 480VAC, it utilizes a thermal-magnetic mechanism with an interchangeable trip unit and adjustable magnetic settings.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | LA3200 |
| Series | LA |
| Amperage | 200A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 30kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | LA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Westinghouse PRL4 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG-350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Lugs |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Interchangeable Trip Unit |
Product FAQs
6 answersWhat panelboards and enclosures are compatible with the LA3200?
This breaker is designed to bolt directly into vintage Westinghouse PRL4 panelboards, switchboards, and motor control centers.
Is there a modern replacement for the LA3200?
Yes, for modern upgrades, the legacy LA3200 is replaced by the Eaton Series C LD3200 circuit breaker.
How does the adjustable magnetic trip function work on this breaker?
The LA3200 features a thermal magnetic mechanism with a fixed thermal element for overload protection and an adjustable magnetic setting. This allows you to customize the instantaneous short-circuit trip threshold for your specific application.
Are the lugs on the LA3200 rated for both aluminum and copper wire?
Yes, the factory lugs accept either aluminum or copper conductors ranging from 4 AWG to 350 kcmil.
Can the LA3200 be used in DC applications?
Yes, this breaker is rated for use in DC systems up to 250VDC, where it provides a 10kA interrupting capacity.
Does this Eaton breaker replace older Westinghouse LA3200 models?
Yes, Eaton acquired the Cutler-Hammer and Westinghouse breaker lines. The Eaton LA3200 is a direct replacement for the original Westinghouse and Cutler-Hammer LA3200 breakers.
