Eaton / Moeller FAZ-G40-3 Miniature Circuit Breaker
- 40A
- 3 Pole
- DIN Rail
Quantity
Eaton / Moeller FAZ-G40-3 - 40A 3 Pole Miniature Circuit Breaker
New
Quantity
Description
Part of Eaton's FAZ series, the FAZ-G40-3 miniature circuit breaker is built for commercial and industrial applications. It provides robust protection for equipment housed in DIN rail enclosures. The three-pole breaker installs onto standard DIN rails for seamless integration. It is officially replaced by the FAZ-K40/3 or FAZ-C40/3.Specifications
| Brand | Eaton / Moeller |
|---|---|
| Part Number | FAZ-G40-3 |
| Series | FAZ |
| Amperage | 40A |
| Poles | 3 |
| Mounting Style | DIN Rail |
| Voltage | 240VAC, 480Y/277VAC, 415VAC |
| Phase | 3 |
| AIC Rating | 15kA @ 240VAC, 10kA @ 480Y/277VAC, 15kA @ 415VAC |
| Terminal Type | Box Lugs |
|---|---|
| For Use With | DIN Rail Enclosures, Control Panels, Eaton FAZ Series |
| Wire Gauge | 18-4 AWG |
| Max Wire | 4 AWG |
| Min Wire | 18 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Curve | G |
| Trip Adjustability | Fixed |
| Available Options | Auxiliary Switch, Shunt Trip, Undervoltage Release, Padlock Attachment, Busbar System |
|---|---|
| Standards | IEC 60898, IEC 60947-2 |
| Approval | CE, VDE |
| Temp Rating | -40C to 75C |
| Construction Features | Current Limiting, Trip-Free Mechanism, Visual Trip Indicator, Reverse Feed |
Product FAQs
5 answersWhat are the recommended direct replacements for the FAZ-G40-3?
This legacy Klockner Moeller breaker is officially replaced by the Eaton FAZ-K40/3 or FAZ-C40/3 models.
Is the FAZ-G40-3 rated as a UL 489 branch circuit breaker or a UL 1077 supplementary protector?
It is a UL 1077 supplementary protector. It is designed to safeguard control panels and equipment where branch circuit protection is already provided upstream.
What applications are best suited for the G-curve trip characteristic on this breaker?
The G-curve trip profile is optimized for inductive loads, making it ideal for industrial motor control and circuits where moderate to high inrush currents are expected.
Does the FAZ-G40-3 support reverse feed wiring?
Yes, this breaker is suitable for reverse feed applications. It also includes a trip-free mechanism and a visual trip indicator to assist with safe operation and troubleshooting.
Are the box lug terminals on the FAZ-G40-3 finger-safe?
Yes, the box lug terminals are designed to be finger-safe, reducing the risk of accidental contact with live electrical parts during maintenance.
