Federal Pacific NFJ634250NA - 250A 3 Pole Molded Case Switch
New
Quantity
Description
Part of the legacy N-frame series, the NFJ634250NA is a 250A, three-pole molded case switch. It functions solely as a non-automatic disconnect, providing circuit isolation without overcurrent protection. This bolt-on device serves as an exact replacement for older Federal Pacific panelboards. It ensures a precise fit within existing enclosures without requiring retrofit adapters. Rated for an 18kA short-circuit withstand at 480VAC, the unit includes line and load lugs for quick integration.Specifications
| Brand | Federal Pacific |
|---|---|
| Series | NFJ |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 480VAC |
| Phase | 3 |
| AIC Rating | 18kA @ 480VAC |
| Frame Type | NFJ |
|---|---|
| Terminal Type | Lugs |
| For Use With | Federal Pacific Panelboards |
| Wire Gauge | 4 AWG - 350 kcmil |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Adjustability | Fixed |
|---|
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | UL 489, NEMA AB-1 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | Non-Automatic (Disconnect) |
