Federal Pacific NEJ223225 Molded Case Circuit Breaker
- 225A
- 2 Pole
- Bolt-On
Quantity
Federal Pacific NEJ223225 - 225A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Maintaining legacy power distribution networks demands precise component matching. This 225-amp, two-pole molded case breaker is tailored for commercial and industrial facilities utilizing classic FPE hardware. Compatibility remains a top priority for facility managers dealing with older gear. This N-Frame unit mounts into classic Federal Pacific panelboards, acting as a dependable cross-reference for the UBIFPE225N.Specifications
| Brand | Federal Pacific |
|---|---|
| Part Number | NEJ223225 |
| Series | NEJ |
| Amperage | 225A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | NEJ |
|---|---|
| Terminal Type | Lugs |
| For Use With | Federal Pacific Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Undervoltage Release, Auxiliary Switch, Bell Alarm |
|---|---|
| Accessories | Load Side Lugs |
| Standards | NEMA AB 1, UL 489 |
| Approval | UL |
| Temp Rating | 40°C |
| Construction Features | Non-Interchangeable Trip, Reverse Feed |
Product FAQs
6 answersWhat panelboards accept the NEJ223225 circuit breaker?
This breaker is designed to install directly into legacy Federal Pacific panelboards configured for N-Frame or NEJ bolt-on molded case circuit breakers.
Are aftermarket adapter kits required to mount this breaker?
No. The NEJ223225 is an exact-fit replacement for original Federal Pacific N-Frame slots and bolts directly into the panelboard without requiring modification or adapter kits.
What aftermarket part numbers cross-reference to the NEJ223225?
This Federal Pacific breaker serves as a direct replacement for original 225A, 2-pole NEJ units and crosses over to aftermarket substitutes such as the UBIFPE225N.
What type of trip functions are included on this breaker?
It utilizes a non-interchangeable thermal-magnetic trip unit equipped with fixed long-time and instantaneous (LI) trip functions to protect against overloads and short circuits.
What wire sizes are compatible with the terminals on this breaker?
The included load-side lugs accommodate wire gauges ranging from 4 AWG to 300 kcmil.
Is this breaker compatible with Federal Pacific Stab-Lok load centers?
No. The NEJ223225 is a commercial-grade bolt-on molded case circuit breaker and will not fit in residential Stab-Lok load centers.
